With multi-protocol compatibility, high reliability, and flexible expansion features, this module has become a preferred component for automation upgrades in industries such as electric power, manufacturing, and energy. Its modular design and adaptability to harsh environments perfectly meet the core needs of modern industry for precise control and stable operation.
Specifications and Parameters:
Output Specifications
Equipped with 16 independent relay output channels, supporting both AC and DC dual load types. The rated load voltage range is 250VAC/30VDC, with a single-channel current rating of 5A and a surge current tolerance of up to 10A. It can directly drive various actuators such as motors, solenoid valves, and contactors without the need for additional adapter modules.
Communication Capabilities
Compatible with mainstream industrial communication protocols including PROFIBUS, Modbus, Ethernet/IP, and EtherCAT. It integrates RS-232, RS-485, and Ethernet interfaces, and supports expansion with 2 serial ports and 2 USB ports. This enables seamless connection with ABB AC 800M controllers and third-party systems, with a data transmission delay of less than 5 milliseconds.
Power Supply and Power Consumption
Both input and output voltages are 24VDC, with a rated power of 5W. The low-power design reduces system energy consumption. Meanwhile, it supports 220-380V wide voltage adaptability (for some application scenarios) to fit different industrial power supply environments.
Environmental Adaptability
The operating temperature range is -40℃ to 70℃, and the storage temperature range is -40℃ to 85℃. It has 2500VAC isolation capability between channels and the backplane, and its electromagnetic interference resistance complies with the IEC 61131-2 standard. Certified by ATEX, it can operate stably in harsh electromagnetic environments such as welding workshops and around high-voltage equipment.
Physical Specifications
With dimensions of 70×40×25 mm, it adopts a compact modular design. It supports stack expansion and direct on-machine installation, which greatly saves control cabinet space and simplifies the system integration process.
ABB XDD501A101 3BHE036342R0101 Communication Digital Output Module
