The Emerson Ovation system comprises seven redundant Model 5X00241G02 digital central processing units (CPUs), seven four-screen operator stations, a historical data server, a domain controller, and an engineering station, all connected via a fully redundant copper Ethernet network. Each CPU pair includes a local node with eight branches per node, supporting up to eight input/output (I/O) electronics and personality module pairs (Figure 24). The system also includes one remote node with eight remote branches for controlling two facility heater engines, and two remote nodes each with eight remote branches for controlling the PSL–3 inclement weather systems.
5X00241G02 Functional Features:
Control Strategy Execution: It can implement simple or complex regulation and sequential control strategies. According to preset rules and algorithms, it can accurately control various parameters in industrial production processes to ensure the stability and reliability of production.
Data Collection and Processing: It performs data collection functions, real-time collecting various data from production sites, such as temperature, pressure, flow, etc. It also processes, analyzes, and stores these data to provide a basis for system monitoring, optimization, and fault diagnosis.
System Connection and Communication: It connects with the Ovation network and different I/O subsystems. Through a fully redundant copper Ethernet network, it performs high-speed data transmission and communication with components in the system, such as operator stations, historical data servers, and engineering stations, to achieve the collaborative operation of the entire control system.
5X00241G02 Technical Architecture
Open Architecture: It employs a powerful real-time operating system running on a PCI bus PC architecture. This design enables the system to easily integrate rapidly evolving new technologies, protects users' software investments, and facilitates system upgrades and expansions to adapt to changing industrial control requirements.
Powerful Computing Capability: It can create up to 32,000 points, meaning it can handle large volumes of process data and control tasks. With high computing speed and processing power, it meets the real-time control and data processing requirements of complex industrial scenarios.
Appearance and Interfaces: It typically features standard industrial module dimensions and form factors for easy installation in control cabinets or racks. It is equipped with various interfaces for connecting power supplies, I/O modules, networks, and other relevant devices, enabling hardware integration with the entire control system.
Reliability Design: As a critical component of industrial control systems, it features high-reliability design. Redundancy technologies, such as redundant power supplies and communication links, ensure the system can continue normal operation in the event of component failures, minimizing downtime and enhancing production continuity and stability. Additionally, it has strong anti-interference capabilities to operate stably in harsh industrial environments.
