The ABB UAC383AE01 HIEE300890R0001 Binary Input Board serves as a powerful assistant in industrial automation, demonstrating exceptional performance. With 16 independent input channels, it efficiently collects various switching signals in parallel, providing abundant data for system operation. Its wide input voltage range of 18 to 30 VDC allows adaptation to multiple power environments, while consuming only 6mA at the standard 24V DC—balancing energy efficiency and stability. Each input channel is meticulously equipped with current limiting, EMC protection components, and opto-isolation barriers to effectively resist electrical noise interference, ensuring precise signal transmission. The board features an outstanding grouping and monitoring mechanism: two independent isolated groups combined with voltage monitoring inputs instantly feedback any voltage anomalies, fully safeguarding the stable operation of industrial control systems.
Appearance Dimensions and Weight
Dimensions: Approximately 15.2cm × 5.1cm × 25.4cm
Weight: Approximately 0.5kg
Series and Application
Possibly belongs to ABB's S800 I/O series.
Used for collecting switching signals in industrial automation systems, receiving digital signals (such as switch status, sensor outputs, etc.), and converting them into digital signals for the control system.
Input Characteristics
Input Channels: 16 independent input channels.
Input Voltage: Range of 18 to 30 VDC, with a standard input voltage of 24V DC.
Input Current: 6mA at 24V.
Grouping and Monitoring: Inputs are divided into two independent isolated groups, each with 8 channels and a voltage monitoring input. If the voltage disappears, the process voltage monitoring input will give a channel error signal.
Input Channel Composition: Each input channel consists of a current limiting element, EMC protection element, input status indicator LED, and an opto-isolation barrier.
Functional Features of ABB UAC383AE01 HIEE300890R0001 Binary Input Board
Diverse Input Types: Supports dry contacts, wet contacts, normally open/closed types, etc., meeting requirements of different application scenarios.
Isolation Protection: Equipped with isolation protection to prevent electrical noise and interference from affecting signal quality, ensuring stable and accurate signal transmission.
Easy Configuration & Debugging: The module features simple configuration and debugging functions, facilitating user setup, troubleshooting, and maintenance.
Rich Communication Interfaces: Supports multiple interfaces like Ethernet, serial port, and CAN bus, enabling easy connection to various devices and sensors.
High Reliability: Adopts high-quality components and manufacturing processes, offering stable performance, high reliability, and long service life to meet the strict reliability and stability requirements of industrial automation.
Application Fields
Widely used in CNC machinery, metallurgy, oil & gas, petrochemical, chemical industry, papermaking & printing, textile & dyeing, machinery, electronics manufacturing, tobacco, plastic machinery, power, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, power transmission & distribution, and other fields.
