Note; All products on this site are special products, the market price has been fluctuating, the specific customer service offer shall prevail, because the product is a new product, the picture is not a real shot, please confirm with customer service before placing an order model and product, price and other details, the site used, new are for sale, please contact customer service communication. Woodward 9907-1183 is a digital governor control module designed for steam turbines, serving as a core component of the Woodward 505E series. Adopting advanced digital control technology, this module can precisely regulate the rotational speed of steam turbines, ensuring stability and reliability in application scenarios such as power generation and mechanical drive. It features built-in multiple protection mechanisms, which can real-time monitor the operating status of the steam turbine and respond quickly in case of abnormalities, effectively preventing equipment damage. As an integrated solution, it supports seamless integration into existing control systems, simplifying the upgrade process. Leveraging Woodward's industry-leading technology, the 9907-1183 provides accurate and efficient control means for industrial steam turbines, and is widely used in fields such as electric power, petrochemicals, and metallurgy.
Basic Information
- Type: Digital governor control and protection module.
- Input Voltage: 24V DC.
- Output Voltage: 0-10V DC.
- Operating Temperature Range: -40°C to 85°C.
- Dimensions: 120mm x 80mm x 40mm.
- Weight: Approximately 1.0kg.
- Communication Protocol: Modbus RTU.
- Communication Interfaces: RS232, RS485.
Functional Features
- Precise Speed Control: Provides accurate speed control for industrial steam turbines, small turbine generators, or utility turboexpanders, with a wide speed range.
- Comprehensive Protection: Equipped with full turbine safety protection functions to safeguard against hazards such as overspeed, underspeed, and bearing failures.
- Advanced Control Algorithms: Utilizes advanced control algorithms to optimize turbine performance and efficiency.
- Digital Monitoring & Control: Functions as a digital input module, capable of receiving and converting various switch signals into digital signals for digital monitoring and control of external devices and signals. It supports high-speed data acquisition and can be configured with multiple I/O sensors and actuators.
- Flexible Configuration: Offers flexible configuration options to meet specific application requirements, with support for user programming for logic control and parameter settings.
- Diagnostic Capabilities: Features comprehensive diagnostic functions to monitor system operation and identify potential issues.
- Resistance to Harsh Environments: Constructed with durable materials and rated IP67, it can withstand harsh industrial environments, offering vibration and shock resistance, operation in extreme temperatures, and excellent electromagnetic compatibility to minimize electromagnetic interference.
Working Principle
During the speed-up process before grid connection, through closed-loop speed control with zero error, the deviation signal between the measured actual speed of the unit and the set speed is analyzed and processed by software and subjected to PID calculation. A standard current signal is then output to the electro-hydraulic converter, which further controls the opening of the regulating steam valve to achieve zero-error speed control.
After the unit is connected to the grid, power closed-loop control or valve position control can be adopted as needed. The unit's power or load is adjusted by controlling the opening of the regulating valve. In case of load rejection, the load regulation will automatically switch to speed regulation mode.
Application Fields
