The DS215SLCCG1AZZ01B communication card is compatible with the management and control systems of various automated drive devices such as wind, steam, and gas turbines. Relying on GE's patented Speedtronic control system technology, it mainly undertakes core tasks including data transmission and command interaction between drive devices and control systems. Its modular design allows it to be seamlessly integrated into various complex industrial control architectures, establishing a stable and reliable communication support system for real-time monitoring, dynamic parameter adjustment, and instant fault feedback during turbine operation.In addition, the DS215SLCCG1AZZ01B can collaborate with the system to achieve rapid response to various operational abnormalities, effectively ensuring the safe and stable operation of key industrial equipment such as turbines. At present, it has been widely applied in core industrial fields such as power generation.

Hardware Structure and Interfaces

Jumpers and Connection Ports: It includes Berg-type manually removable hardware jumpers and hard-wired jumpers, facilitating users to perform hardware configuration according to system requirements. In terms of ports, the 2PL interface is the power supply interface, the 3PL interface is used to connect to the driver's control card, the 10PL interface provides LAN I/O terminal board connection for the Local Area Network Control Processor, and the ARCNET interface is used to realize communication transmission of DLAN and ARCNET protocols.

Core Functions

System Diagnosis and Configuration: It supports accessing the system through a module programmer and an alphanumeric keyboard, allowing users to perform fault diagnosis, parameter configuration and other operations via this channel. The jumper settings and hardware configuration information of the board are clearly marked in the official operation manual, facilitating debugging and maintenance by technical personnel.

Technical Parameters

Adaptability and Compatibility

As key components of the Mark V series, the GE DS200SLCCG1AEE ,DS215SLCCG1AZZ01B LAN communication cards are compatible with a variety of I/O boards and control boards in the same series, such as the STCA board, TCQC board, and TCTG board. They establish a data bus connection with core boards like the STCA and TCQA via the 3PL connector, and transmit pulse signals, generator signals, and line signals to the TCQC board through the JE connector, enabling the coordinated operation of the entire gas turbine control system. Their standardized interface design also ensures high compatibility with GE series turbine drive devices.
