CI855K01 3BSE018106R1 is a high-performance, high-reliability communication interface module specifically designed for ABB's AC 800M controller, which serves as the core of its process control station. Its core function is to enable the connection between the AC 800M controller and the MB 300 fieldbus network. MB 300 is a proprietary, high-speed, and deterministic fieldbus developed by ABB, primarily used to connect its Advant® series I/O modules (such as S800 I/O) and other devices that support this bus.
This module is a key component in building ABB's distributed control systems (such as ABB Advant Master or systems integrated with System 800xA), facilitating high-speed and reliable data exchange between the controller and remote I/O stations.
Package including: - CI855, MB300 Interface Module - TP853, Base plate
DATA SHEET
CI855K01 3BSE018106R1 MB 300 Interface.pdf
Basic Information
Product Model: CI855K01
Product Number: 3BSE018106R1
Product Name: CI855K01 MB 300 Interface (MB 300 Dual Ethernet Port Interface Module)
Product Type: Communication Module
Package Contents: Includes CI855 MB300 interface module and TP853 base
Country of Origin: Sweden (SE)
Physical Parameters
Dimensions:
Length: 65 mm
Height: 203 mm
Width: 157 mm
Net Weight: 0.62 kg
Core Function Positioning
As a key communication component in the AC 800M control system, the CI855K01 mainly undertakes the MasterBus 300 interface function. It realizes data transmission and communication connection between devices through dual Ethernet ports, and is suitable for information interaction between the control system and external devices in industrial automation scenarios, providing stable communication support for systems such as 800xA.
