Note; All products on this site are special products, the market price has been fluctuating, the specific customer service offer shall prevail, because the product is a new product, the picture is not a real shot, please confirm with customer service before placing an order model and product, price and other details, the site used, new are for sale, please contact customer service communication. The ABB PP845 (product number: 3BSE042235R1) is an industrial-grade touch operation panel in the Panel 800 series, specifically designed for human-machine interaction in industrial automation scenarios. It is equipped with a 10.4-inch high-resolution resistive touchscreen, supporting both text and graphic display. Compatible with ABB AC 800M controllers and mainstream third-party PLCs, it enables seamless device integration through a rich set of communication interfaces. Featuring a robust powder-coated aluminum enclosure, the product achieves an IP66 front protection rating, allowing it to withstand harsh industrial environments. It is widely used in on-site operation and equipment control across industries such as chemical engineering, pharmaceuticals, water treatment, and marine engineering.
Download of Relevant Documents
PP845 3BSE042235R1.pdf
Panel 800-PP845.pdf
Compact HMI 800.pdf
Core Features and Advantages
High-Definition Touch Control and Intuitive Operation
- Equipped with a 10.4-inch TFT-LCD display with a resolution of 800×600 pixels, supporting 64K color display for clear and delicate images.
- Features a resistive touchscreen designed to withstand 1 million touch operations, paired with an Autotex F157/F207 protective surface layer for wear resistance and corrosion resistance.
- Supports core functions such as process graphics, alarm events, trend curves, and report viewing. The operation logic is consistent with Windows interaction habits, ensuring easy 上手 (quick mastery).
Comprehensive Communication and Flexible Compatibility
- Equipped with RS232C (9-pin D-sub male) and RS422/RS485 (25-pin D-sub female) serial interfaces to meet multi-protocol communication needs.
- Onboard shielded RJ45 Ethernet interface (10/100 Mbit/s) supports high-speed data transmission and remote connection.
- Dual USB interfaces (Host Type A + Device Type B) facilitate convenient expansion by supporting external storage, keyboards, and other peripherals.
- Compatible with industrial protocols such as Modbus and PROFIBUS DP, and can enhance communication capabilities through expansion modules, adapting to multi-brand automation equipment.
Industrial-Grade Rugged Design
- Front protection rating of IP66 and rear protection rating of IP20, providing dust and water resistance to adapt to harsh factory environments with dust and humidity.
- The enclosure is made of powder-coated aluminum material, offering vibration resistance and impact resistance, meeting industrial-grade mechanical strength requirements.
- Wide operating temperature range (0°C-50°C for vertical installation, 0°C-40°C for horizontal installation) and storage temperature range (-20°C-70°C), adapting to temperature conditions in various scenarios.
Safety, Reliability, and Stable Operation
- Built-in real-time clock with a CR2450 lithium battery (service life ≥ 3 years) to ensure stable storage of time data.
- Supports maintenance functions such as system restoration, firmware upgrade, and touchscreen calibration, with quick access to corresponding modes via mode switches.
- Compliant with multiple certifications including UL 1604 Class I Div 2 and DNV classification society, meeting the usage requirements of hazardous locations and special industries.
Technical SpecificationsBasic InformationProduct number: 3BSE042235R1; Product type: Industrial touch operation panel; Applicable series: Panel 800 4.1/5.0/5.1Display and Touch ControlScreen size: 10.4 inches; Resolution: 800×600 pixels; Display color: 64K; Touch type: Resistive; Touch life: 1 million timesMemory ConfigurationFlash memory: 32 MB (Intel StrataFlash); RAM: 64 MB; Application flash memory: 12 MB (including fonts)Communication InterfacesEthernet: Shielded RJ45 (10/100 Mbit/s); RS232C: 1 (9-pin D-sub male); RS422/RS485: 1 (25-pin D-sub female); USB: Host Type A + Device Type B (USB 1.1);
CF card slot: Supports Type I/II Compact Flash cardsPower ParametersSupply voltage: 24 V DC (20-30 V DC); Normal power consumption: 0.5 A; Maximum power consumption: 1.0 A;
Built-in fuse: 3.15 AT (5×20 mm)
Physical Specifications
Front dimensions (W×H×D): 302×228×6 mm; Installation depth: 58 mm (including 158 mm gap); Weight: 2.1 kg (net weight 2.7 kg);
Enclosure material: Powder-coated aluminum; Front surface layer: Autotex F157/F207Environmental ParametersOperating temperature: 0°C-50°C (vertical) / 0°C-40°C (horizontal); Storage temperature: -20°C-70°C; Relative humidity: 5%-85% (non-condensing);
Vibration resistance: Compliant with industrial-grade standards
Application Scenarios
- On-site operation and monitoring of industrial automated production lines, such as chemical reactor control and pharmaceutical equipment parameter adjustment.
- Equipment control in special environments like marine and offshore engineering, meeting the certification requirements of classification societies.
- Human-machine interaction terminals for small and medium-sized process control systems, adapting to control scenarios with ABB AC 800M and third-party PLCs.
- Harsh industrial environments with strict requirements on protection rating and temperature adaptability, such as dusty workshops and humid workshops.
