ABB DSDO 110 (Part No. 57160001‑K) is a digital output board of the S100 I/O series manufactured by ABB in Sweden. As a core I/O module for industrial automation control systems, it is specially designed for ABB DCS and PLC platforms including 800xA and Advant OCS. The module outputs digital on-off signals to drive actuators such as relays, contactors and indicator lights, serving as a key component for on-site signal control and equipment actuation in industrial applications.
DOCUMENT DOWNLOAD
DSDO 110 Digital Output Board 57160001-K.pdf
Product Advantages
Native System CompatibilityFully compatible with mainstream control systems including ABB 800xA, Advant OCS (Master SW/MOD 300 SW) and MasterPiece 200/200/1. It features plug-and-play operation with no additional adaptation or development required.
High-Reliability Industrial DesignManufactured in compliance with ABB industrial quality standards. With excellent electromagnetic interference resistance and vibration tolerance, it delivers stable long-term operation in harsh industrial environments and minimizes downtime risks.
Compact & LightweightDimensions: 324 mm (D) × 225 mm (W) × 22.5 mm (H), net weight: only 0.375 kg. It saves cabinet space and facilitates easy installation and maintenance.
Low Maintenance CostFree from WEEE compliance restrictions and boasting a long service life. It supports hot-swap replacement, enabling quick module changeover during faults and reducing system downtime.
Product Features
Basic Specifications
Model: DSDO 110 (57160001‑K)Type: Digital Output ModuleDimensions: 324mm × 225mm × 22.5mmWeight: 0.375 kgPlace of Origin: Sweden
Functional Characteristics
Multi-channel OutputEquipped with 32 galvanically isolated relay digital outputs, supporting 24–250V AC/DC discrete signals for most industrial actuators.
Electrical IsolationGalvanic isolation between channels and the system side suppresses interference and protects control loops and field devices.
Fast ResponseHigh-speed signal processing meets the real-time requirements for rapid start/stop and interlock control applications.
Protocol SupportCompatible with industrial buses such as PROFIBUS-DP to ensure high-speed and stable communication with host systems.
Diagnosis & ProtectionBuilt-in fault diagnosis circuitry enables rapid detection of channel faults, short circuits, overloads and other anomalies.
Application Scenarios
Power IndustryApplied in DCS systems of thermal power plants and hydropower plants to control valves, dampers, relays, alarm indicators and other equipment.
Process IndustryWidely used in process sectors such as petrochemical, metallurgy, cement and papermaking to actuate on-site on-off valves, contactors, audible and visual alarm devices.
Manufacturing IndustryDeployed in PLC systems of discrete manufacturing including automotive, electronics and food processing industries for the control of production line start/stop, conveyors, safety doors and status indicators.
InfrastructureSuitable for control systems of water treatment, HVAC and rail transit, realizing on-off control and status indication for pumps, fans and valves.
User Guide
Pre-installation Preparation
Verify the module model (57160001‑K) and its compatibility with control systems such as 800xA and Advant OCS.
Perform all operations with the power disconnected. Wear an anti-static wrist strap to prevent electrostatic damage to the board.
Check that the cabinet guide rails are intact and ensure installation space of 324mm × 225mm is reserved.
Hardware Installation
Align the module with the cabinet guide rails, slide it in smoothly and lock it securely to ensure reliable contact.
Connect the system communication cables (e.g. PROFIBUS‑DP) and field output terminals. Double-check channel numbers and load types.
Software Configuration
Add the DSDO 110 module in configuration software like ABB Control Builder, and set the address and communication parameters.
Configure output types (normally open / normally closed) and fail-safe states according to load requirements.
Download the configuration to the controller and restart the system for module recognition.
Commissioning & Maintenance
After power-on, check the module status via the system diagnostic interface and confirm no fault alarms.
Test each output channel one by one to verify proper operation of connected loads.
Inspect terminal wiring and communication status regularly. Keep the module clean to avoid dust accumulation.
FAQ
Q: What should I do if the DSDO 110 module cannot be recognized by the system?A: ① Confirm the module model is correct (57160001‑K); ② Check the communication cable connection and terminal resistor settings; ③ Re-download the configuration and restart the controller; ④ Check the module indicator lights to troubleshoot hardware faults.
Q: How to troubleshoot when a single output channel fails to work?A: ① Check for loose wiring or damaged loads on the channel; ② Check for channel error alerts via the system diagnostic interface; ③ Test with another channel to determine whether the fault lies with the module or the load; ④ Replace the module via hot swap if the module is defective.
Q: Why does the module frequently report errors during operation?A: ① Severe on-site electromagnetic interference. Check grounding and add shielding measures; ② Short circuit or overload of the load. Verify the load parameters; ③ Unstable power supply voltage. Inspect the output of the power module; ④ Module aging or damage. Contact ABB after-sales service for inspection.
Q: Does this module support hot swapping?A: Yes. It can be replaced while the system is running. The system will automatically recognize the new module without shutdown, saving maintenance time.
Q: Can the outputs of DSDO 110 directly drive a 220V AC contactor?A: Yes. The built-in relay contacts support 24–250V AC/DC, so it can directly drive contactors of the corresponding voltage without an intermediate relay.
