ABB TAS.580.0540G00 Power Quality Control Board
The ABB TAS.580.0540G00 is a dedicated main control board for ABB power quality equipment, part number 1TGB302003R0003. Equipped with multi high-performance DSP chips, it acts as the core control unit for Active Power Filter (APF) and Static Var Generator (SVG) systems.
It samples grid voltage and current signals, calculates harmonics, reactive power and unbalance components, executes control algorithms and sends PWM commands to power modules. It also implements system protection logic, fault diagnosis and data communication between power quality equipment and upper monitoring systems.
Key Features
- High-speed sampling of 3-phase voltage & current
- Real-time calculation of harmonics, reactive power and negative sequence
- PWM closed-loop control for power units
- Built-in protection: overvoltage, undervoltage, overcurrent, overtemperature
- Digital I/O and communication interfaces for status & alarm transmission
- Event log and fault waveform recording for troubleshooting
Specifications
- Model: TAS.580.0540G00
- Item No.: 1TGB302003R0003
- Power Supply: 220V AC
- Max switching frequency: 30kHz
- Digital Output: 16 channels, 10~30V DC, 0.5A max per channel
- Weight: 1.59kg
Applications
Industrial power distribution, power generation, chemical, metallurgy, data center and other sites with non-linear loads, for harmonic suppression and dynamic reactive compensation.
Benefits
- ABB industrial-grade hardware with strict EMC & thermal aging test
- Multi-DSP high-speed real-time control for fast load tracking
- Highly integrated design reduces wiring and failure points
- Hot-swap friendly structure for quick replacement and less downtime
- Multiple software & hardware protection layers to safeguard power system
Note: This board is a spare component for complete APF/SVG systems. It cannot work independently. Firmware download and signal calibration are required after replacement.
Frequently Asked Questions
Q: What is ABB TAS.580.0540G00 used for?
A: ABB TAS.580.0540G00 is a dedicated power quality control main board, specially designed for ABB APF active power filters and SVG static var generators. It is responsible for grid signal sampling, harmonic analysis, reactive power calculation, PWM output and system protection.
Q: What is the part number of TAS.580.0540G00?
A: The official ABB material number is 1TGB302003R0003, which corresponds to the model TAS.580.0540G00.
Q: Can TAS.580.0540G00 work independently?
A: No. This control board is a supporting component for complete power quality equipment. It cannot run independently. It needs to match power units, transformers and official firmware to work normally.
Q: What functions does the ABB power quality control board support?
A: It supports 3-phase voltage and current high-speed sampling, harmonic suppression, reactive power compensation, three-phase unbalance adjustment, PWM closed-loop control, fault alarm, data communication and event recording.
Q: What industries is TAS.580.0540G00 suitable for?
A: Widely used in industrial power distribution, chemical industry, metallurgy, rail transit, power plants, data centers and other scenarios with large non-linear loads to improve grid power quality.
Q: What protection functions does this board have?
A: It integrates multiple protection mechanisms including overvoltage, undervoltage, overcurrent, overtemperature and communication fault protection, which can effectively protect the whole SVG/APF equipment and power modules.
Q: Is TAS.580.0540G00 an original ABB spare part?
A: Yes. TAS.580.0540G00 (1TGB302003R0003) is a genuine industrial-grade spare part of ABB power quality series, with stable performance and long service life.
Q: Does the board need calibration after replacement?
A: Yes. After replacing the TAS.580.0540G00 control board, it is necessary to re-download the supporting firmware and complete signal sampling calibration to ensure accurate compensation effect.
We supply original ABB TAS.580.0540G00 (1TGB302003R0003) Power Quality Control Board, professional after-sales support, fast delivery and complete technical documents. If you need model matching, technical parameters or bulk quotation, please contact us.
