This module adopts advanced microprocessor technology and a modular structure. It features strong processing capabilities, stable communication transmission performance and excellent environmental adaptability. These attributes enable it to efficiently accomplish core tasks such as data acquisition, signal processing, equipment control and remote monitoring and diagnosis.The module is widely compatible with multiple fields, including industrial production lines, process control, energy management and building automation.

Core Technical Parameters

I/O Configuration

It is equipped with 16 digital input channels and 16 digital output channels, supporting simultaneous acquisition and control of multiple signals. The input current is 5mA per channel, and the output current can reach 500mA per channel, which meets the signal interaction needs of most industrial equipment.

Voltage and Communication

The input and output voltage ranges are both 0-24VDC, compatible with common industrial power supply standards. It supports multiple industrial communication protocols such as TCP/IP, allowing easy integration into existing industrial networks to achieve efficient data interaction with other devices.

Storage and Performance

It has a built-in 16MB RAM and 8MB flash memory, providing sufficient space for data processing and program storage, and ensuring the efficiency of instruction execution and the reliability of data. It has fast processing capabilities, which can meet the needs of control tasks at different speed levels.

Environmental Adaptability

The operating temperature range is -25°C to 60°C, the storage temperature range is -40°C to 85°C, and the humidity adaptability range is 5% to 95% non-condensing, enabling stable operation in harsh industrial environments. It has an IP65 protection rating, which effectively resists external interference and environmental erosion.

Physical Characteristics and Installation

The product dimensions are 158mm × 105mm × 58mm, with a weight of approximately 300g, featuring a compact structure. It adopts a DIN rail mounting method, which is easy to install and maintain, and can be flexibly configured and expanded according to actual needs.

Core Advantages of the Product

High Reliability: Manufactured with high-quality materials and equipped with complete isolation functions, it can effectively prevent external interference, ensure the stability of long-term continuous operation, and reduce the failure rate.

Flexible Adaptability: The modular design supports expanded configuration on demand. It is compatible with the ABB AC 800PEC controller series and third-party product systems, and adapts to various application scenarios from compact equipment to complex industrial systems.

Convenient Operation and Maintenance: It supports remote monitoring and diagnosis functions. Operation and maintenance personnel can grasp the module's operating status in real time, quickly locate and solve problems, which greatly simplifies the maintenance process and reduces operation and maintenance costs.

Rich Functions: It has functions such as signal conditioning, amplification, and filtering to ensure the accuracy of signal transmission. In some application scenarios, it can realize special functions such as arc detection, automatic arc extinction and re-ignition, and voltage fluctuation measurement, which is suitable for special industrial needs such as arc furnaces.

Application Fields

Industrial Automation: Widely used in the control of equipment such as electrical control cabinets, robots, CNC machine tools, and frequency converters, improving the automation level and accuracy of the production process.

Energy and Process Industry: Suitable for the monitoring of power generation, transmission, and distribution systems, as well as process control in industries such as chemical engineering, oil and natural gas, pharmaceuticals, and food processing, ensuring stable energy supply and compliance with production processes.

Building and Equipment Monitoring: Can be integrated into building automation systems to realize signal acquisition and output. It can also be used for equipment health monitoring, predicting and preventing equipment failures through the acquisition of parameters such as temperature.
