The GE DS6800CCIE1F1D is a critical component of the Mark VI control system, specifically engineered for power distribution in gas turbine and steam turbine control applications. This robust power distribution module provides reliable power management for control system components, ensuring stable operation in demanding industrial environments.
Designed to meet the rigorous requirements of power generation and industrial control applications, the DS6800CCIE1F1D features advanced protection mechanisms, modular design, and high reliability characteristics that are hallmarks of GE's industrial control solutions.
As part of the Speedtronic Mark VI control system family, this module integrates seamlessly with other system components, providing comprehensive power distribution capabilities for turbine control systems.
Key Specifications
Integral part of GE Mark VI control system
2.Redundant power distribution capabilities
3.Industrial-grade components and construction
4.Overvoltage and overcurrent protection
5.Hot-swappable design for easy maintenance
6.Operating temperature: -40°C to +70°C
7.Conformal coating for harsh environments
8.Complies with industry safety standards
Technical Specifications
| Electrical Characteristics | |
|---|---|
| Input Voltage | 125V DC nominal (100-140V DC range) |
| Output Voltage | Multiple outputs: 5V DC, 12V DC, 24V DC |
| Output Current Capacity | 5V: 20A, 12V: 10A, 24V: 5A |
| Power Consumption | Maximum 150W |
| Protection Features | Overvoltage, overcurrent, short circuit protection |
| Isolation | Input to output: 2500V AC |
| Mechanical Specifications | |
| Dimensions (H×W×D) | 254mm × 178mm × 229mm (10" × 7" × 9") |
| Weight | Approximately 2.5 kg (5.5 lbs) |
| Mounting | Rack-mountable in standard Mark VI cabinets |
| Environmental Ratings | |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature | -55°C to +85°C (-67°F to +185°F) |
| Humidity | 5% to 95% RH, non-condensing |
| Vibration Resistance | 5-2000Hz, 15g, per MIL-STD-810G |
Technical Features & Benefits
Redundant Design
Dual power input capability with automatic switchover ensures uninterrupted power distribution even during primary power source failure.
Comprehensive Protection
Advanced protection circuits guard against overvoltage, overcurrent, and short circuit conditions, protecting both the module and connected equipment.
Industrial-grade Construction
Robust design with conformal coating and ruggedized components ensures reliable operation in harsh industrial environments with high vibration and temperature extremes.
Hot-swappable
Designed for replacement without system shutdown, minimizing downtime and maintenance costs in critical applications.
Intelligent Monitoring
Integrated diagnostics and monitoring capabilities provide real-time status information and predictive maintenance alerts.
Seamless Integration
Designed specifically for integration with GE Mark VI control systems, ensuring optimal performance and compatibility.
