The CCC TMPU‑1002 is an industrial-grade Transition Module launched by Compressor Controls Corporation (CCC) in the United States. It is specially designed for the control systems of key power equipment such as compressors and turbines. The module enables seamless signal switching and electrical isolation between different CPU platforms, signal types and communication protocols. Serving as a core adaptation unit for new & old system upgrades and heterogeneous equipment interconnection, it is widely deployed in high-reliability control scenarios of process industries including oil & gas, power generation and chemical engineering.
Manufacturer Profile
- Brand: CCC (Compressor Controls Corporation)
- Brand Positioning: A global leading supplier of compressor and turbine control solutions. It focuses on the R&D of high-reliability control systems for extreme working conditions, with products renowned for outstanding industrial stability and long service life.
Core Functions
Signal Conversion & Adaptation
- Input: Compatible with analog signals (4–20 mA, 0–10 V) and digital signals (dry contact / wet contact).
- Output: Standard industrial signals (4–20 mA, 0–10 V, relay dry contact). It features a conversion accuracy of ±0.1% FS and a response time of less than 1 ms, fully meeting the requirements of real-time closed-loop control.
Electrical Isolation & Anti-Interference
Adopts three-way isolation (input / output / power supply) with a isolation voltage of 2500 Vrms. It effectively blocks ground loop current, surge voltage and electromagnetic interference, protects upstream and downstream equipment, and optimizes the overall EMC performance of the system.
Protocol Conversion & Communication Bridging
Supports mainstream industrial protocols including Modbus RTU/TCP and EtherNet/IP, realizing interconnection between CCC Extreme Eng CPUs and third-party PLCs, DCS systems and remote I/O modules.
As a transition bridge for legacy and new CPU platforms, it facilitates the upgrade of outdated systems (e.g., CCC Legacy CPU) to modern architectures without full hardware replacement, greatly reducing downtime and renovation costs.
Modular Expansion & Hot-Swap Support
Designed for standard 35 mm DIN rail mounting and supports hot swapping. Modules can be replaced and maintained online without disrupting system operation.
It is perfectly compatible with other CCC control modules (I/O modules, communication modules, etc.) to allow flexible system expansion.
Technical Specifications
1. Electrical Characteristics
- Power Supply: 24 V DC (±10%)
- Power Consumption: ＜15 W
- Isolation: 3-way isolation (input/output/power), 2500 Vrms for 1 minute
- Ingress Protection: IP20 (cabinet installation)
2. Signal Processing
- Analog Input: 4–20 mA (250 Ω impedance), 0–10 V (＞100 kΩ impedance)
- Analog Output: 4–20 mA (≤500 Ω load), 0–10 V (≥10 kΩ load)
- Digital Input: 24 V DC wet contact (NPN/PNP), dry contact
- Digital Output: Relay dry contact (250 V AC / 30 V DC, 5 A)
- Conversion Accuracy: ±0.1% FS (@25 ℃)
- Response Time: ＜1 ms (analog signals)
- Resolution: 16 bit
3. Environmental Parameters
- Operating Temperature: −40 ℃ ~ +70 ℃
- Storage Temperature: −55 ℃ ~ +85 ℃
- Humidity: 5% ~ 95% RH (non-condensing)
- Vibration Resistance: IEC 60068‑2‑6, 10 Hz ~ 150 Hz, 0.15 mm
- Shock Resistance: IEC 60068‑2‑27, 15 g, 11 ms
4. Mechanical Dimensions
- Dimensions: 176 mm × 110 mm × 70 mm (W × H × D)
- Weight: Approx. 0.4 kg
- Mounting: Standard 35 mm DIN rail, hot-swap capable
5. Communication Interfaces
- Serial Port: RS‑232/RS‑485 (Modbus RTU)
- Ethernet: 10/100 Mbps (Modbus TCP, EtherNet/IP)
Application Scenarios
- Compressor Control System Upgrade: Connect legacy CCC Legacy CPU with new-generation Extreme Eng CPU, retaining existing I/O and wiring to minimize downtime.
- Heterogeneous System Interconnection: Realize signal and protocol conversion between CCC control systems and third-party PLC/DCS brands (Siemens, Rockwell Automation, etc.).
- Isolation & Anti-Interference Protection: Signal isolation and transmission protection in harsh environments with strong electromagnetic interference (variable frequency drives, high-voltage equipment).
- Multi-Signal Integration: Standardized conversion of on-site diversified analog and digital signals for unified access to the central control system.
FAQ
Q1: What is the core function of TMPU‑1002?A1: As a transition and conversion module, it realizes compatibility between new & old CPU platforms, multi-type signal conversion, communication protocol adaptation and electrical isolation. It acts as a critical connection hub for system upgrading and cross-brand equipment interconnection, cutting renovation and maintenance costs.
Q2: Does it support hot swapping? Is system shutdown required for module replacement?A2: Hot swap is supported. The module can be replaced online during normal system operation without shutdown, and no interruption will be caused to control logic and data transmission.
Q3: What is the isolation voltage? How about its anti-interference capability?A3: It adopts 3-way isolation for input, output and power supply, with a dielectric withstand voltage of 2500 Vrms (1 minute). It restrains ground potential difference, surge and electromagnetic interference efficiently, suitable for harsh industrial working conditions.
Q4: What about analog conversion accuracy and response speed?A4: It provides a conversion accuracy of ±0.1% FS (@25 ℃), ultra-fast response time within 1 ms and 16-bit resolution, meeting high-speed closed-loop control demands of compressors, turbines and other core equipment.
Q5: What communication protocols are supported? Is connection with third-party devices available?A5: It supports Modbus RTU/TCP and EtherNet/IP. Direct connection with third-party PLCs, DCS systems and remote I/O is available to realize data exchange and control signal interaction.
Q6: What is the operating temperature range? Can it be used outdoors or in high-temperature environments?A6: Adopting industrial wide-temperature design, the operating temperature ranges from −40 ℃ to +70 ℃, adaptable to outdoor cabinets and high-temperature workshops. Non-condensing humidity and sun/rain protection are required for outdoor deployment.
Q7: What is the rated power supply? Is ordinary industrial 24 V power supply applicable?A7: It adopts standard 24 V DC (±10%) power supply, compatible with widely used industrial 24 V DC switching power supplies. With power consumption below 15 W, no high-power power supply is required
