The Motorola MVME162-220 is an embedded VME board based on Motorola's VME bus standard, widely used in industrial control, automation systems, embedded computing and other fields. It boasts advantages such as high performance, high reliability, modular design and wide compatibility. However, it also has disadvantages like high cost, large power consumption and high technical threshold.
Hardware Specifications
Microprocessor
Equipped with MC68LC040 or optional MC68040 microprocessor. The MC68040 integrates a floating-point coprocessor, which significantly enhances the speed and precision of floating-point operations in data processing—suitable for high-demand scenarios requiring complex industrial control algorithm calculations. The MC68LC040 does not include this coprocessor.
Memory
Offers 1MB, 4MB, or 8MB of parity-protected DRAM for storing running programs and data, ensuring data accuracy and system stability.
Features 512KB of battery-backed SRAM to retain critical data and configurations during power outages.
Interfaces
Two serial ports (EIA-232-D and EIA-232-D/EIA-530) for serial communication with devices like sensors and controllers.
Optional LAN Ethernet transceiver interface with DMA support for high-speed network communication, enabling remote monitoring and data interaction.
Six timer counters, including a watchdog timer for system timing control and fault detection. The watchdog triggers protective actions when system anomalies are detected.
Optional SCSI bus interface with DMA support for connecting external storage devices to expand system storage capacity.
Functional Features
High-Performance Data Processing and Transmission
Based on the VME bus standard, a full 32-bit workstation-class bus initially applied in m68000 computer systems and recognized by IEEE as the IEEE-1014 bus standard in 1985. The bus delivers high-bandwidth, low-latency data communication, enabling the MVME162-220 module to handle massive data and exchange information rapidly with other devices/modules. This suits applications demanding strict data processing speed and transmission efficiency, such as real-time data acquisition and processing systems in industrial automation.
High Reliability
As a mature and stable technology, the VME bus is widely adopted and recognized. The MVME162-220 module benefits from this bus technology's stability, offering high reliability for systems requiring long-term stable operation—critical in industrial control systems where uninterrupted operation is essential to ensure system stability.
Modular Design Advantages
With a modular design, it easily combines and expands with other VME bus modules to build complex control systems. This design simplifies system maintenance and upgrades, allowing users to flexibly configure systems by adding or replacing modules, thus reducing development and maintenance costs and difficulties.
Wide Compatibility
Due to the VME bus being a widely used standard, the MVME162-220 module interoperates with numerous other VME-compliant devices, providing users with broader options and facilitating integration with various equipment across different application scenarios.
Application Fields
Industrial Control
Used in industrial automation production lines to control the operation of various equipment, such as motion control of robotic arms and monitoring/regulation of parameters like temperature and pressure in production processes. With its high-performance data processing capability and multiple interfaces, it achieves precise control and real-time monitoring of production processes, enhancing production efficiency and product quality.
Automation Systems
Suitable for various automation systems, including factory automation and logistics automation. In factory automation, it serves as the core control unit to connect sensors, actuators, and other devices for automated control of the entire production process. In logistics automation, it controls automated warehousing and transportation equipment to improve the efficiency and accuracy of logistics operations.
Embedded Computing
Plays a critical role in embedded systems, such as flight control systems in aerospace, electronic systems of military equipment, and control units of medical devices. These scenarios have strict requirements for equipment reliability, performance, and size. The MVME162-220 module stands out with its high reliability and compact design
