The SS6073R2P3 is a 10-port smart switch (19-inch rack-mount modular model) with a port configuration including 6 10/100BASE-TX RJ45 ports, 4 100/1000 combo ports, and 2 module slots. It features a redundant power supply and is equipped with a European power cord. Without media modules, it has a power consumption of 7.3W, a power output of 26.9 Btu (IT)/h, and a weight of 3.60Kg. Additionally, it supports hot-swappable expansion modules, such as the 8-port media modules in the SS6074 series (including types like TX, multimode fiber, single-mode fiber, or 100Mb SFP transceivers).
Advantages of SS6048R2P3 Smart 8-port Switch:
Dedicated to safety and strong isolation: The LSN and GSN of DeltaV SIS are dedicated to the safety field, carrying only safety-rated signals and isolated from the control network. They are therefore immune to any failure of the control network, avoiding the possibility of common-cause control and safety communication failures.
Fast update speed: All the data broadcast on the LSN is available to every CSLS on the same LSN every 50 milliseconds. Combined with the speed of the CSLS, when the CSLS is configured for 50-millisecond scan rate, it guarantees input-to-output time of less than 300 milliseconds anywhere on the LSN.
Plug-and-play components: As a dedicated safety network with predictable communications traffic, Emerson has done all of the system testing so you only have to plug the components together to create the safety networks.
Standards compliance: Network components are compliant with standards such as IEEE, CE, and CSA.
High scalability and cost-effectiveness: You can expand the system readily and economically by adding hardware incrementally. Just plug another CSLS into the LSN and it is recognized by the system, and online addition of new CSLSs will not interrupt your process.
Fully redundant communications: The safety networks are fully redundant communication networks. The carriers for all nodes have redundant safety network ports for communication with primary and secondary network connections.
Port mirroring functionality: Port Mirroring can be configured on the NextGen Safety Network Switches either with an “administrator” role or an “engineer” role. These switches have the capability to mirror the traffic of several source ports, in a read-only manner, to a destination port (probe port).
Support for specific topologies and cross-network communication: The SZ controllers and CSLSs can be physically connected as a star topology, and the LSNB allows communication across multiple LSNs following a star topology. Starting with v14.LTS and later, the GSN can be logically separated in domains, enhancing network flexibility and manageability.
Suitable for SIL 3 applications: Both the LSN and GSN are certified for use in SIL 3 applications.
No complex configuration required for devices: For example, LSNB requires no configuration to function on the safety networks, and DeltaV SIS Smart Switches also require no configuration to function on the safety network.
EMERSON DeltaV SIS SS6048R2P3 Smart 8-port Switch
