Note; All products on this site are special products, the market price has been fluctuating, the specific customer service offer shall prevail, because the product is a new product, the picture is not a real shot, please confirm with customer service before placing an order model and product, price and other details, the site used, new are for sale, please contact customer service communication. HIMA H6200A is a high-precision current conversion device. It is mainly used to convert sensor signals into standard 4-20 mA current output signals, facilitating remote monitoring and data transmission, and is widely applied in industrial automation and process control systems.
Specification Parameters
Power Supply Parameters: Usually adopts DC power supply, possibly 24V DC. Some data show that the working power supply is 85 - 265VAC, 50Hz, 10W.
Working Environment: The operating temperature is generally -10℃ - 50℃, and the humidity is less than 95% RH (no condensation).
Sensor - Related: The sensor power supply may be 5V/100mA, the sensor operating temperature is ≤300℃, and the operating pressure is ≤3Mpa.
Accuracy and Resolution: The instrument accuracy class may be Class 3, the resolution can reach 0.01mm, and the maximum linear error is 0.05mm.
Sampling and Output: The sampling rate is more than 200 times per second, the analog output is 12 - bit, and the 4 - 20mA current signal is provided.
Display Parameters: It may adopt a 6 - digit LED nixie tube (double row) for display, and the maximum display division number is 100000 divisions.
Protection Level: The protection level is IP55, and the explosion - proof level is Exia IICT4.
Overall Dimensions: The overall dimensions are 45 (H) * 95 (W) * 163 (D) mm, and the opening dimensions are 41 (H) * 90 (W) mm.
Application Areas:
- PLC & DCS Integration: Can be integrated with PLC (Programmable Logic Controller) and DCS (Distributed Control System) for real-time data monitoring and adjustment.
- Real-Time Monitoring: Converts sensor signals into actionable data for system performance optimization.
- Hazardous Area Monitoring: Monitors critical parameters (e.g., gas leaks, temperature, pressure) in high-risk environments and transmits alarms via 4-20mA signals to control systems.
Circuit Composition (Speculative):
- Power Supply: Typically uses a 24V DC power source with resistors for circuit division (e.g., power supply resistor and current output resistor).
- Sensor Unit: The core component that detects physical changes and converts them into electrical signals, possibly using resistive strain gauges or similar principles with compensation circuits.
- Amplifier Circuit: Boosts weak sensor signals to the 4-20mA standard range, composed of operational amplifiers and adjustable resistors to calibrate the output current.
- Overload Protection: Prevents damage from voltage spikes or pressure surges using components like current-stabilizing diodes and fuses.
- Output Circuit: Converts the amplified current signal into a voltage via resistors and supplies operational voltage to external measurement or control devices.
Working Principle:
The sensor converts physical parameters into electrical signals, which undergo conditioning (amplification, filtering, linearization) before being converted into a standardized 4-20mA current signal. This signal is then transmitted to control systems or display units via the output circuit.
