The GE VMIPCI-5565-110000 is a high-performance pulse control module based on the PCI bus, specifically designed for industrial automation, precision testing and measurement, and other scenarios. It enables accurate acquisition, generation, counting, and timing control of high-speed pulse signals. Compatible with 32-bit/33MHz PCI/CPCI buses and supporting both 3.3V and 5V bus levels, the module can be seamlessly integrated into various industrial control computers and embedded systems. Boasting low latency, high stability, and flexible configuration, it meets the stringent requirements for pulse control accuracy and real-time performance in applications such as servo control, stepper motor driving, and precision positioning.
The bus interface adopts a 32-bit/33MHz PCI/CPCI bus, is compatible with 64-bit/66MHz transmission, and supports 3.3V/5V bus levels. The pulse input features multi-channel differential inputs, supports 5-24V DC signals, and has a maximum counting frequency up to the hundreds of megahertz range. The pulse output is equipped with independently programmable channels, supports pulse width modulation (PWM) and pulse sequence generation, and the output levels are compatible with industrial standards. For counting functions, it supports multiple modes including rising/falling edge counting, pulse width measurement and period measurement, with a 32-bit high-speed counter and a counting accuracy of ±1 pulse. The timing accuracy reaches the nanosecond level with its internal clock, supporting microsecond-level adjustment of pulse period and width. The operating environment allows a working temperature range of -40℃ to 70℃ and adopts an industrial-grade electromagnetic interference resistant design. The power supply requirements include a wide voltage input of 12-24V DC, with overvoltage and overcurrent protection functions.
Core Functional Features
High-reliability Design: It features hardware-level CRC check to automatically detect and correct transmission errors. The onboard self-test function displays channel status and fault information via indicator lights, facilitating quick debugging and maintenance. It supports redundant configuration to cope with complex working conditions in industrial sites.
Convenient Configuration and Management: It provides drivers and configuration tools for Windows (Win2000/XP/7, etc.), supporting register-level programming and a graphical configuration interface. Channel functions, counting rules and output parameters can be flexibly defined through software. There is no need to manually set MAC ID addresses via jumpers, which reduces deployment difficulty.
Application Scenarios
