Honeywell FC-IOCHAS-0001R is an industrial-grade redundant I/O module chassis specially designed for distributed control systems (DCS) such as Experion PKS.It is positioned as a highly reliable, redundant mounting and communication carrier for critical process control applications.
Featuring triple redundancy in power supply, communication, and heat dissipation, it eliminates single points of failure.It supports hot-swappable I/O modules to ensure uninterrupted operation and seamless switching during module or link failures.It is widely used in industries with strict requirements for continuous production and safety, including petroleum, chemical, power, metallurgy, and pharmaceuticals.
The chassis is compatible with mainstream redundant I/O modules such as Honeywell C-Series and Process Manager Series, enabling flexible expansion of analog, digital, pulse, and other signal acquisition and control functions.
It serves as core foundational hardware for building high-availability industrial automation systems.
Core Technical Parameters
| Parameter Item | Specification |
|---|---|
| Model | FC-IOCHAS-0001R |
| Application | Redundant I/O module mounting, compatible with Experion PKS, C300 Controller, etc. |
| Module Capacity | Supports up to 9 pairs of redundant I/O modules (18 single modules) |
| Power Supply | 24VDC (dual redundant power supply, seamless switchover) |
| Communication | Dual redundant communication links, compatible with FTE, I/O LINK, etc. |
| Physical Size | 19-inch standard rack mount, approx. 31.3cm × 27.8cm × 3cm |
| Weight | Approx. 3kg (industrial-grade metal material) |
| Operating Temperature | -40℃ ~ +70℃ (wide-temperature industrial grade) |
| Heat Dissipation | Redundant fans for high-density installation cooling |
| Mounting | Standard cabinet rail mounting |
| Key Features | Hot-swappable, redundant switching, fault diagnosis, electromagnetic immunity |
Core Product Advantages
- Full-link Redundancy: Triple redundancy in power, communication, and cooling ensures system operation is unaffected by single-component failure, achieving zero downtime.
- High Compatibility & Scalability: Compatible with the full range of Honeywell redundant I/O modules, supporting flexible expansion of signal types and channel counts.
- Industrial-grade Durability: Metal enclosure and wide-temperature design adapt to harsh industrial environments with strong anti-vibration and anti-interference performance.
- Easy Maintenance: Supports hot-swappable I/O modules, allowing online replacement of faulty modules without system shutdown.
- Seamless Integration: Deeply compatible with Honeywell C300 Controller and Experion PKS system, simplifying system configuration and commissioning.
Related Core Models
Below are key Honeywell models in the redundant I/O/control system family, including chassis, I/O modules, controllers, and related components:
- FC-IOCHAS-0003R: Redundant I/O chassis in the same series with higher expansion capacity
- CC-PAIM01: C-Series analog input module (redundant type, compatible with FC-IOCHAS-0001R)
- CC-PDOB11: C-Series digital output module (for redundant configuration)
- CC-TDIL11: C-Series digital input module with hot-swap and redundancy support
- CC-TAON11: C-Series analog output module for redundant chassis
- FC-IO-0001: Basic I/O module (non-redundant, compatible with the same series)
- CC-PCNT01: C300 controller processor module, works with redundant I/O chassis
- CC-PCF901: C-Series control firewall module for redundant communication security
- 51190582-150: Fuse assembly for C-Series I/O modules, suitable for redundant chassis
- 900P01-0101: HC900 series redundant controller, compatible with matching redundant I/O chassis
