It integrates complete engine‑generator control and protection functions with advanced peer‑to‑peer paralleling capability. It enables single‑unit island operation, multi‑unit (up to 32 units) parallel load sharing, as well as grid connection / switching with mains power (AMF/ATS), covering full scenarios including emergency standby, peak shaving, and continuous operation.Featuring built‑in LogicsManager programmable logic and AnalogManager analog management functions, it allows highly customized control without the need for an additional PLC. It also supports rich communication interfaces for seamless integration into SCADA and remote monitoring systems.

related documents

easYgen 3200XT.pdf

Core Technical Specifications

1. General Specifications

• Model: 8440‑2082 (easYgen‑3200XT‑P1)
• Series: easYgen‑3000XT
• Power supply: 12/24 VDC (range: 8–40 VDC), power consumption ≤14 W
• Protection class: Front panel IP66 (screw‑mounted) / IP54 (clip‑mounted); rear side IP20
• Dimensions: 282×216×96 mm (W×H×D), cutout 249×183 mm
• Weight: approx. 1.85 kg
• Operating temperature: -20°C to +70°C (-LT version: -40°C)

2. Measurement & Control

• Voltage / Current: True RMS measurement, supports 3‑phase detection for generator, busbar and mains
• CT input: 1A (5A optional)
• Paralleling capability: Single / multi‑unit parallel operation, up to 32 generating sets, single mains system
• Control functions: Engine start/stop, speed control / voltage regulation, synchronizing & paralleling, load sharing, breaker control, AMF/ATS switching
• Programmable logic: LogicsManager™, supporting custom logic, timers, status interlocking
• Analog management: AnalogManager™, flexible configuration of analog inputs / outputs

3. Communication Interfaces

• Ethernet: 1 port, supports Modbus TCP, remote monitoring and configuration
• CAN: 2 ports (CANopen + J1939), for engine ECU communication (supports SAE‑J1939 and major OEM protocols)
• Serial: RS‑485 (Modbus RTU slave)
• USB: Local configuration and firmware upgrade
• Remote panel: Supports RP‑3200XT remote touch panel (CANopen, up to 250 m)

4. Protection & Certifications

• Protection: Comprehensive protection including over/undervoltage, over/underfrequency, overcurrent, reverse power, phase sequence, earth fault, engine overspeed, water temperature, oil pressure, etc.
• Certifications: CE, UL/cUL, CSA, BDEW, ABS, LR, etc.

Key Functions & Advantages

• Full‑Scenario Control: Single-unit islanding, multi‑unit paralleling, mains paralleling / switching, peak shaving, AMF auto start
• Customization Without PLC: Built-in programmable logic greatly reduces system complexity and cost
• High Compatibility: Works with all major global engine ECUs and supports multiple communication protocols
• Easy Configuration & Maintenance: Visual configuration via Woodward ToolKit software, supports remote diagnostics and upgrades

• High Reliability: Industrial‑grade hardware, wide temperature range, full isolation, suitable for harsh operating conditions

•

easYgen Series Models

• easYgen‑3100XT‑P1 (8440‑2081): Basic parallel model, ideal for small‑to‑medium multi‑unit systems
• easYgen‑3200XT‑P2 (8440‑2083): Enhanced parallel controller with expanded I/O and functions
• easYgen‑3400XT‑P1 (8440‑2078): Designed for complex distribution systems, supports multiple bus sections
• easYgen‑3500XT‑P2 (8440‑2079): Flagship model, supports up to 32 generating units + 32 busbars, multi‑mains feed
• easYgen‑600 (8440‑1800): Compact single‑unit AMF controller with basic LCD
• easYgen‑800 (8440‑1801): Advanced single‑unit controller, large LCD, Ethernet, SD card expansion
• easYgen‑1000 (8440‑1900): For mobile / special gen-sets, flexible breaker configuration
• easYgen‑1400 (8440‑1901): Enhanced version of easYgen‑400 with AMF function
• easYgen‑400 (8440‑2231/2250): Basic single‑unit automation controller, remote start/stop
• easYlite‑100 (37279): Ultra‑compact entry‑level model for small standby gen-sets
