AKT 0100-71498 and 0100-71429 are standardized split-type EtherCAT digital I/O module under the AKT brand, designed for signal acquisition and execution control of distributed automation equipment. These two part numbers correspond to identical hardware bodies, differing only in internal channel logic configuration files.
Compliant with the EtherCAT CoE standard protocol, the equipment is equipped with dual RJ45 bus ports to support daisy-chain wiring. It integrates multiple isolated digital input and output channels, compatible with 24V industrial standard sensors and solenoid valve loads.
The unit features clip-on mounting for standard DIN35 rails and an IP20-rated enclosure suitable for centralized wiring inside control cabinets. It supports mainstream EtherCAT master controllers on the market including CODESYS, Beckhoff and Omron, and is widely applied for station point expansion of production line equipment, signal acquisition for tooling inspection, and peripheral control of small motion equipment.
Product Features
- Communication Protocol: Fully compliant with EtherCAT IEC61158 standard; supports CoE PDO/SDO parameter read-write and distributed DC clock synchronization.
- Bus Interface: 2-channel RJ45 100 Mbps Ethernet ports; maximum transmission distance between stations reaches 100 meters, stable communication achievable with CAT5 industrial network cables.
- Electrical Specifications: 24 V DC operating voltage with allowable fluctuation range of ±20%; overall static power consumption less than 130 mA (excluding external load current).
- Channel Isolation: All input and output channels adopt independent optoelectronic isolation with 500 V AC isolation voltage, eliminating common-ground interference between channels.
- Input Channels: NPN/PNP signal types optional; 3 ms input filter; logic low level: 0–7 V, logic high level: 18–30 V; single-channel input current 3 mA.
- Output Channels: Transistor version with max. 0.5 A per channel; relay version with 5 A resistive load contact capacity; output status can be latched or reset after power failure as selected.
- Mounting Structure: Clip-on mounting for standard DIN35 top-hat rails; tool-free assembly and disassembly clips; IP20 enclosure protection rating.
- Environmental Adaptability: Operating temperature range: -20 ℃ ~ +60 ℃; storage temperature range: -25 ℃ ~ +85 ℃; ambient humidity 5%–95% non-condensing; compliant with EN60068 vibration and shock standards.
- Compliance Certifications: CE and RoHS certified; conforms to EN61131-2 general specifications for industrial equipment.
- Fault Diagnosis: Hardware-level fault reporting; fault codes for bus disconnection, undervoltage, channel short-circuit and load overcurrent can be read via the master station.
Application Industries
- Automated Assembly Production Lines: Detection signals of tool fixture in-place status, output control of cylinder solenoid valves, signal acquisition for photoelectric sensors detecting material presence/absence
- CNC Machining Equipment: Machine tool door status monitoring, tool detection, cooling pump start-stop control, point expansion for limit switches
- Packaging & Printing Equipment: Conveyor belt start-stop control, bin material shortage alarm, cutting-sealing mechanism motion control, signal collection from counting sensors
- Lithium New Energy Equipment: Cell positioning detection, diaphragm cutting cylinder control, dust removal fan switching, safety door interlock signals
- Logistics Sorting Equipment: Sorting track switchover, cargo photoelectric identification, lifting platform limit monitoring, trigger signals for code scanning devices
- Rubber & Plastic Injection Molding Equipment: Mold proximity switches, ejector mechanism control, heating fault alarm signals, silo material level detection
- Food Processing Equipment: Conveyor operation control, cleaning valve regulation, packaging in-position detection, safety guard door interlock
- Compact Robot Workstations: Auxiliary peripheral cylinders, material sensors, signal expansion for safety light curtains
Product Comparison
| Comparison Item | AKT 0100-71498 | AKT 0100-71429 | AKT Digital Input Only Module 0100-71386 | AKT Transistor Output Only Module 0100-71512 |
|---|---|---|---|---|
| Channel Configuration | 16-channel NPN Input + 16-channel Transistor Output | 16-channel PNP Input + 16-channel Relay Output | 32-channel PNP Digital Input | 32-channel NPN Transistor Output |
| Output Load Capacity | 0.5A DC per channel for light loads | 5A universal AC/DC for heavy loads | No output channels | 0.5A DC per channel |
| Compatible Loads | Photoelectric sensors, small indicator lamps | Cylinder solenoid valves, contactors, high-power indicator lamps | Signal acquisition only, no actuators | Small DC valves, indicator lamps |
| Module Thickness | 18 mm | 18 mm | 14 mm | 14 mm |
| Isolation Type | Optoelectronic isolation | Optoelectronic isolation + physical relay isolation | Optoelectronic isolation | Optoelectronic isolation |
| Applicable Scenarios | Scenarios with balanced input/output points & light load control | Applications requiring high-power drive and frequent load switching | Dense multi-point signal acquisition only | Driving multiple small DC actuators only |
Recommended Models of Same Brand
0100-71386: 32-channel PNP digital input EtherCAT IO module
0100-71392: 32-channel NPN digital input EtherCAT IO module
0100-71512: 32-channel NPN transistor digital output module
0100-71527: 32-channel PNP transistor digital output module
0100-71415: 16-input 16-output PNP relay EtherCAT module
0100-71498: 16-input 16-output NPN transistor EtherCAT module
0100-71429: 16-input 16-output PNP relay EtherCAT module
0100-71603: 8-channel 4-20mA analog input EtherCAT module
0100-71611: 8-channel 0-10V analog output EtherCAT module
0100-71705: 4-channel incremental encoder acquisition module
0100-71802: Basic EtherCAT bus coupler
0100-71816: EtherCAT bus coupler with power expansion
0100-71901: 4-channel PT100 temperature acquisition IO module
0100-72006: IO-Link master EtherCAT expansion module
0100-72109: 8-channel relay digital output module
