Note; All products on this site are special products, the market price has been fluctuating, the specific customer service offer shall prevail, because the product is a new product, the picture is not a real shot, please confirm with customer service before placing an order model and product, price and other details, the site used, new are for sale, please contact customer service communication. ABB DSCA114 (Order No. 57510001-AA) is an asynchronous RS232/V24 communication board designed for Advant Master/OCS control systems. As a communication module of the MasterPiece series, it enables data exchange between controllers and serial port devices. Featuring a compact structure and easy installation, it fully meets industrial reliability standards.
DOCUMENT DOWNLOAD
DSCA114 Communication board 57510001-AA.pdf
Product Advantages
Native System AdaptationSpecially designed for ABB Advant OCS and MasterPiece 200/200/1 controllers. It connects seamlessly to the internal Controlway bus with excellent compatibility and operational stability.
Wide Temperature Range & High Anti-Interference CapabilityBuilt to industrial standards with wide temperature tolerance and superior electromagnetic compatibility, suitable for harsh operating environments in factories, energy facilities, water treatment plants and more.
RoHS Exemption ComplianceQualified for exemption under Directive 2011/65/EU, complying with environmental regulations for special industrial applications.
Lightweight & Easy IntegrationWeighing only 0.4 kg with dimensions of 324mm×234mm×18mm, it saves cabinet space and supports standard rack mounting.
Product Features
Core Specifications
Model: DSCA114Order No.: 57510001-AA
Communication Interface: RS232/V24 asynchronous serial port
Physical Dimensions: 324mm (L) × 234mm (W) × 18mm (H)Weight: 0.4 kg
Environmental Compliance: Classified as small equipment (≤50cm) under WEEE directive; RoHS exempted
Functional Characteristics
Asynchronous CommunicationAdopts standard RS232/V24 interface and supports point-to-point serial data transmission.
System InterconnectionCommunicates with MasterPiece controllers via Controlway bus to expand serial port capacity.
Industrial ReliabilityDeveloped with rigorous EMI/EMC design, capable of resisting voltage fluctuations and electromagnetic interference in industrial sites.
Application Scenarios
Process ControlDeployed in DCS systems for power, chemical, water treatment and other industries to connect serial instruments, analyzers and controllers.
Manufacturing AutomationApplied to automotive, electronic and packaging equipment to interface with serial sensors, barcode scanners and HMI terminals.
Energy ManagementUsed in power plants, photovoltaic and wind farms to collect data from serial power meters and temperature controllers for remote monitoring.
Intelligent BuildingsIntegrated into building automation systems to centrally manage serial-connected lighting, air conditioning and security equipment.
FAQ
Q: What serial port protocols does DSCA114 support?A: It adopts standard RS232/V24 asynchronous communication and supports serial protocols such as ASCII and Modbus RTU. It does not come with native Ethernet protocol.
Q: Does it support hot swapping?A: No. Power off the device before installation or removal to prevent damage to the bus and hardware.
Q: Which ABB controllers is it compatible with?A: It is only compatible with MasterPiece 200, 200/1 and Advant OCS systems, and cannot be used with series such as AC500.
Q: Will the RoHS exemption affect its application?A: No. The exemption applies to special usage of industrial control equipment and complies with EU environmental regulations. The product can be sold and used normally.
Q: How to troubleshoot unstable communication?A: ① Check wiring (cross connection of TXD/RXD and common GND);
② Verify consistent serial parameters including baud rate and parity bits;
③ Eliminate electromagnetic interference by keeping the module away from inverters and motors;
④ Check bus status via system diagnostic tools.
