The ABB 5SHY6545L0001 AC10272001R0101 5SXE10-0181 belongs to an Integrated Gate - Commutated Thyristor (IGCT). The IGCT combines the advantages of IGBT and GTO. It has a capacity comparable to that of GTO, and its switching speed is 10 times faster than that of GTO. Additionally, it can eliminate the huge and complex snubber circuit required in GTO applications. However, it requires a relatively large driving power.
5SHY6545L0001 AC10272001R0101 5SXE10-0181 Performance parameters:
Rated voltage: 6500V
Rated current: 1000A
Switching loss: 5.0J
Switching frequency: 2kHz
Junction temperature: 175°C
Weight: 15 kg
Dimensions: Length 300 mm, Width 250 mm, Height 150 mm
5SHY6545L0001 AC10272001R0101 5SXE10-0181 Application Fields:
Suitable for multiple fields including power control, industrial heating, DC power supply regulation, frequency converters, power modulation, welding equipment, motor control, power adjustment, and energy management.
Functional Features:
The 5SHY6545L0001 AC10272001R0101 5SXE10-0181 adopts advanced digital signal processing technology, featuring high-speed computing and response capabilities to achieve rapid fault detection and protection actions. It supports fault recording and event logging functions, facilitating fault analysis and system optimization. With support for multiple communication interfaces and protocols (such as IEC 61850, Modbus, etc.), it can communicate and integrate with other devices to realize system monitoring and data exchange. Users can also perform logical programming and parameter settings according to actual needs to achieve personalized protection and control functions.
