The Emerson Ovation 5X00594G01 Analog Input Module is engineered specifically for industrial control applications. It features 16 analog channels with a sampling rate of 20kHz and an input range of -10V to +10V. The module enables precise conversion from analog to digital signals and supports various sensor types. Operating on 24VDC, it ensures stable performance in environments ranging from -40°C to +70°C. Leveraging the OPC-UA communication protocol, it facilitates efficient data exchange. With a compact dimension of 244mm x 177mm x 75mm and weighing 0.8kg, it simplifies system integration and enhances the reliability of industrial automation processes.
Emerson Ovation 5X00594G01 Performance Parameters
Analog Channels & Sampling Rate
16 differential analog channels for simultaneous multi-channel signal acquisition.
20kHz sampling rate enables rapid data capture, ideal for high-real-time industrial applications.
Input Range
Supports multiple input ranges:
Voltage: ±10V (standard), with optional custom ranges available.
Current: ±40mA (per select specifications).
Flexible configuration for diverse sensor types and signal sources.
Input Resolution & Accuracy
16-bit resolution ensures fine-grained analog signal quantization.
±0.1% full-scale accuracy guarantees precise signal conversion and measurement.
Communication Protocol & Update Rate
OPC-UA communication protocol enables seamless integration with compatible control systems.
250ms update rate ensures timely data transmission to downstream systems.
Electrical Specifications
Operating voltage: 24VDC for stable performance in industrial environments.
Environmental Adaptability
Operating temperature: -40°C to +70°C
Humidity tolerance: 0-95% non-condensing
Designed for harsh industrial conditions with extended temperature and humidity ranges.
Functional Features
Multi-Sensor Adaptability
Supports various sensor types including thermocouples, resistance temperature detectors (RTDs), current transmitters, and voltage transmitters, ensuring strong compatibility.
Signal Conditioning & Fault Diagnosis
On-board signal conditioning function preprocesses input analog signals.
Integrated fault detection and diagnostic capabilities promptly identify and report operational issues.
Structural Design Advantages
Compact design with dimensions of 244mm × 177mm × 75mm and a weight of approximately 0.8kg (may vary between 530g to 1000g per different specifications), facilitating installation and integration into existing systems.
Standards & Certifications
Complies with relevant international safety and quality standards. Adopts a modular design for easy system expansion and upgrades.
Application Scenarios
Industrial Automation Production Lines
Automotive Manufacturing & Electronics Production: Acquires analog signals such as temperature, pressure, and flow rate to provide data support for precise control of production processes.
Energy Industry
Oil & Gas Extraction/Processing: Monitors various process parameters to ensure production safety and stable equipment operation.
Power Generation: Ensures reliable monitoring of critical parameters in power production systems.
Chemical Industry
Chemical Production Processes: Collects and processes analog signals (e.g., reactor temperature, pressure, liquid level) for precise control of chemical reactions.
