ABB PP895 3BSE092981R1 is a standard 21-inch industrial touchscreen operator panel from the ABB Panel 800 series. As a core HMI device in the Compact Product Suite, it is designed specifically for monitoring and controlling complex industrial processes. It features high-resolution widescreen display, intuitive touch control, and stable, reliable industrial-grade performance, making it suitable for automation scenarios across various industries such as power, chemical, metallurgy, and water treatment.
Download
| Parameter Category | Detailed Specifications |
|---|---|
| Product Model/Order No. | PP895, Order No. 3BSE092981R1 |
| Display Specifications | 21.5-inch TFT/LED widescreen, resolution 1920×1080 (16:9), brightness approx. 500 cd/m² |
| Processor | ARM9 1GHz |
| Memory Configuration | 1GB main memory, 2GB SSD external storage (1.5GB available) |
| Power Supply Requirements | 24V DC (18–32V DC) |
| Operating Environment | Temperature -10℃~+60℃, Humidity 5%–85% (non-condensing), Vibration resistance 1G, Shock resistance 15G |
| Protection Level/Certifications | Front panel IP65/IP66, NEMA 4X, compliant with CE, FCC, UL and other certifications |
| Communication Interfaces | 2×10/100Mbps Ethernet ports, 2×USB 2.0, RS232/RS422/RS485 serial ports, supports multi-protocol communication |
| Dimensions | Approx. 550×380×65mm (W × H × D) |
| Configuration Software | Panel Builder 800 V6.2 |
High-Definition Visual Interaction21.5-inch full HD widescreen with vector graphics technology for crisp visuals. Supports advanced graphics such as dynamic tags and scrolling panels, greatly improving process information visibility and operational efficiency.Open Architecture & Multi-Protocol CompatibilityOpen design based on the .NET framework, enabling seamless connectivity with ABB and third-party PLC/DCS controllers (e.g., AC500, AC800M, S800 I/O). Compatible with major industrial protocols including Modbus, Profibus, and EtherNet/IP.Efficient Engineering DevelopmentPaired with Panel Builder 800 software in a Windows environment. Includes extensive templates and libraries, supports 8 languages, and enables one-click batch style modification, significantly reducing configuration and commissioning time.Flexible Deployment & ExpansionSupports local communication, remote access, and online project updates. USB ports allow easy connection to peripherals, meeting expansion and maintenance requirements in various scenarios.
Installation & Maintenance
Installation
Flush panel mounting, compatible with standard industrial control cabinet cutouts. Ensure proper sealing between the panel and cabinet to maintain IP rating.Powered by a stable 24V DC supply. Use industrial-grade shielded cables for communication to prevent electromagnetic interference.Complete project configuration via Panel Builder 800 before installation, then download to the panel via USB or Ethernet.
Maintenance
Regularly clean the front panel with a lint-free cloth; avoid corrosive cleaning agents. Inspect connections and cables periodically.Perform remote diagnostics via Panel Builder software to monitor operating status in real time and quickly identify faults.Regularly back up firmware and project files. Online updates are supported, allowing system upgrades without shutdown.
Recommended ABB Accessories
ABB Controllers: AC500, AC800M, AC800F and other PLC/DCS controllers for full HMI and control layer integration.I/O Modules: S800 series I/O modules (e.g., AI895, AO895, DI885) for expanded signal acquisition and control.Communication Modules: CI840, CI854 and other bus adapters for various fieldbus protocols.Configuration Software: Panel Builder 800 V6.2, the dedicated tool for project design, simulation, and download.
Recommended Models from ABB Panel 800 Standard Series
- PP875 3BSE092977R1: 7-inch standard touchscreen panel
- PP881 3BSE092978R1: 10.1-inch standard touchscreen panel
- PP883 3BSE092979R1: 12.1-inch standard touchscreen panel
- PP886 3BSE092980R1: 15.4-inch standard touchscreen panel
- PP895 3BSE092981R1: 21.5-inch standard touchscreen panel
