The CCC PSMU-350-34 is a high-performance, high-reliability 350W modular power supply produced by Vanguard (CCC). Designed specifically for industrial automation, DCS control systems and critical equipment applications, it adopts the standard CPCI 6U mechanical form factor, delivers stable DC output, and integrates multiple protection mechanisms.Capable of continuous and stable operation in a wide temperature range from -40°C to +85°C, it serves as an ideal power solution for industrial-grade critical systems.
Technical Specifications
Manufacturer: Vanguard (CCC)Model: PSMU-350-34Input Voltage: 220V three-phase AC / wide-range AC inputOutput Power: 350WOutput Configuration: Multi-channel DC output (+3.3V, +5V, ±12V, etc.)Efficiency: ≥ 90%Operating Temperature: -40°C ~ +85°CDimensions: Standard 6U CPCI form factorProtection Degree: IP00Approvals: CE, FCC, RoHS
Features
High-Efficiency Conversion & Low Loss
Adopts advanced high-frequency switching technology with a conversion efficiency of over 90%, effectively reducing power consumption and heat generation, and extending service life.
Ultra-Stable Output
Built-in precision voltage regulation and filtering circuits deliver extremely low output ripple, ensuring clean and stable power for load equipment free from grid fluctuations.
Comprehensive Protection Mechanisms
- Overvoltage Protection (OVP)
- Overcurrent Protection (OCP)
- Short Circuit Protection (SCP)
- Overtemperature Protection (OTP)
Industrial-Grade Rugged Design
All-metal enclosure and high-grade components provide shock resistance and anti-interference performance, adapting to harsh industrial environments including dust, humidity and high temperatures.
Modular Hot-Swappable Design
Supports online maintenance and replacement without system power down, ensuring continuous operation of critical equipment.
Status Monitoring
Front panel equipped with status indicators (Power / Fault) for real-time operation status display.
Applications
- Industrial automation control systems (DCS, PLC)
- Electric power and energy (power plants, substations)
- Process control (chemical, petroleum refining, pharmaceutical)
- Telecommunication and data equipment
- Rail transit and military equipment
- Precision instruments and medical equipment
Frequently Asked Questions (FAQ)
Q1: What causes the Fault LED on the front panel to light up?A: A steady or flashing Fault LED indicates the module has detected an abnormality and entered protection mode. Common causes include output short circuit, overload, abnormal input voltage, or internal over-temperature. First check for shorted or overloaded loads, ensure input voltage is normal, then repower the module after it has cooled down. If the fault persists, return the unit for factory repair.
Q2: Can the PSMU-350-34 be used in parallel to increase power?A: This model does not support direct paralleling. For higher power requirements, select a higher-wattage model from the same series (e.g., 500W / 900W) or a factory version designed for parallel operation.
Q3: Is high noise during operation normal?A: The built-in intelligent temperature-controlled fan runs at low speed (low noise) under light load, and increases speed (slightly higher noise) under heavy load or high temperature. Continuous sharp abnormal noise or fan stalling is abnormal; shut down the unit immediately for inspection.
Q4: Is a slightly low or high output voltage normal?A: A voltage deviation within ±1% to ±3% is normal for industrial-grade power supplies. Excessive deviation (>5%) or no output usually indicates a fault in the internal voltage regulation circuit; module replacement is recommended.
Q5: Does the module support hot swapping? What should be noted during replacement?A: Hot swapping is supported. During replacement:
- Ensure the new module has the same model and specifications as the original
- Wear an anti-static wristband
- Remove the faulty module and insert the new one quickly
- Verify normal operation by confirming the Power LED is steady and the Fault LED is off
Q6: What is the difference between PSMU-350-34 and PSMU-350-3?A: Both belong to the 350W series. The -34 is an upgraded/customized version of the -3. Main differences include number of output channels, ripple parameters, protection thresholds, or communication interfaces, while form factor and mounting remain compatible.
