The unit receives analog load signals from PFCL and PFTL series load cell transducers. It internally executes tension calculation and PID regulation, then outputs standard analog control signals to drive brakes, clutches and variable-frequency motors, delivering consistent material tension for unwinding, winding and intermediate traction sections.
3BSE003911R230 features a metal enclosure with IP65 outdoor protection rating, differentiating it from the DIN rail-mounted IP20 variant 3BSE003911R115. It supports direct wall-mounted installation on-site without an additional electrical control cabinet, making it widely applicable to new and existing production line retrofits as well as equipment maintenance and replacement projects. The original manufacturer provides complete unit overhaul and spare parts replacement services.
DOCUMENT DOWNLOAD
PFRA 101 Control Unit REPAIR 3BSE003911R230.pdf
Model Code Decoding
Product Advantages
- Dual-channel sensor input, supports two tension load cells simultaneously, balances tension on both sides of wide web material to eliminate edge wandering
- IP65 sealed metal housing, dust and splash water resistant, no extra protective cabinet required for dusty and humid workshops to save cabinet investment
- Original ABB dedicated tension PID algorithm built-in, no complex PLC programming needed, universal factory preset parameters for fast commissioning
- Wide ambient operating range from -20°C to +60°C, supports continuous 7×24h operation under low-temperature northern workshops and high-temperature coating lines
- Optimized anti-electromagnetic interference circuit, stable tension reading without signal drift when matched with shielded cables near inverters and high-power motors
- Dual standard analog outputs: 0-10V DC voltage and 4-20mA current, fully compatible with most tension actuators and upper monitoring instruments on market
- Modular internal circuit design, single circuit board replacement available for faults instead of full unit scrapping, cutting later maintenance and repair cost
- Local operation keypad and digital display integrated, zero PC access required for on-site zero calibration, range adjustment and mode switching
Applicable Industries
Paper Industry: Newsprint, packaging paper, special coated paper slitting, rewinding and coating production lines
Plastic Film Industry: BOPP, PET, PVC film blowing, slitting, laminating and printing equipment
Metal Foil Processing: Copper foil, aluminum strip, stainless steel strip rolling, slitting and surface cleaning lines
Textile & Chemical Fiber Industry: Non-woven fabric, chemical filament, geotextile winding and unwinding tension stabilization
Lithium Battery Material Production: Copper/aluminum foil electrode slitting, diaphragm winding precision tension control
Printing & Packaging Industry: Gravure printing, flexo printing, composite film bag making machine web traction control
Rubber Web Processing: Rubber sheet, waterproof coiled material calendaring and winding processes
Wire & Cable Manufacturing: Optical cable, electric wire insulation extrusion pay-off tension control
Comparison With Same Brand Product
PFRA 101 3BSE003911R230 VS PFEA111 Tension Amplifier
Customers who purchased this product are also browsing the following products:
PFRA 101 3BSE003911R115 Tension Control Unit
- PFRA 101 3BSE003911R230 Tension Control Unit
- PFEA111 3BSE050091R20 Tension Amplifier
- PFEA112 3BSE050092R20 Dual-channel Tension Controller
- PFEA113 3BSE050093R20 High-precision Tension Processing Unit
- PFCL201C 3BSE007913R20 Pillow Type Tension Load Cell
- PFCL201CD 3BSE007914R20 Sealed Cable Tension Sensor
- PFTL101A 3BSE008508R01 Horizontal Tension Force Transducer
- PFTL101AE 3BSE008509R01 Anti-corrosion Tension Sensor
- PFTL201D 3BSE008510R01 Wide Range Web Load Cell
- PFTL301E 3BSE008511R01 High Temperature Tension Sensor
- PFRL101 3BSE004022R01 Tension Signal Relay Module
- PFVC101 3BSE004023R01 Tension Voltage Conversion Module
- PFTA102 3BSE004024R01 Remote Tension Display Indicator
- PFMA101 3BSE004025R01 Multi-channel Tension Acquisition Distribution Unit
Frequently Asked Questions
- Q: How to select between 3BSE003911R230 and R115 PFRA101?A: Choose R230 (IP65 wall mount 230V) for dusty, humid workshops without independent control cabinet; select R115 (IP20 115V DIN rail) if standard control cabinet and rail installation available.
- Q: How many tension sensors can this control unit support simultaneously?A: Hardware maximum capacity 2 PFCL/PFTL series load cells, available for average value control or separate dual-channel monitoring.
- Q: Can single circuit board be replaced for damaged PFRA101 mainboard instead of full unit purchase?A: Official ABB supports split component repair, signal board and power board spare parts available separately to cut procurement budget largely.
- Q: Continuous load cell break alarm displayed on screen, how to troubleshoot?A: Step one check loose waterproof cable terminals; step two measure millivolt output signal of load cell with multimeter; step three replace shielded cable to eliminate wire breakage fault.
- Q: Tension reading fluctuates up and down during web operation, how to adjust?A: Verify reliable equipment grounding with single-end shield grounding for signal cable; reduce PID integral parameter; check mechanical jamming of sensor roller shaft.
- Q: 4-20mA output signal fails to drive magnetic powder clutch, root cause?A: Confirm output load resistance within unit rated range; check short-circuit on output loop; restore factory default setting then re-calibrate measuring range.
- Q: Severe zero offset after long-term shutdown restart, how to fix?A: Unload full web tension and execute one-touch zero calibration via panel; repeat calibration during monthly line shutdown maintenance to retain measuring accuracy.
- Q: How to repair and maintain unit with water or dust intrusion into housing?A: Cut off 230V power supply immediately, disassemble housing and blow internal dust with dry compressed air, dry circuit board and test insulation; replace aging sealing rubber ring to restore IP65 protection grade.
