GD9924BE V2 HIEE401091R0002 high-voltage control board possesses powerful signal processing and precise control capabilities. In medium and high-voltage frequency converter systems, it undertakes the critical tasks of signal acquisition, processing, and control command output. Through high-speed and accurate acquisition of various analog and digital signals, it uses built-in complex algorithms for analysis and processing, and then generates precise control signals to achieve precise driving and regulation of power devices in medium and high-voltage frequency converters. This ensures efficient power conversion and output, providing stable and reliable power support for industrial equipment.
GD9924BE V2 HIEE401091R0002 Specification Parameters:
Operating Voltage: 24VDC (±10%)
Power Consumption: ≤15W
Input Signals:
Analog: ±10V/±20mA
Digital: 24VDC
Output Pulses:
Optocoupler-isolated
Peak current ≥2A
Timing accuracy ±5ns
Communication Interfaces:
PROFIBUS DP (12Mbps)
Modbus RTU (115.2kbps)
Fiber optic interface
Performance Indicators:
Signal processing: 16-bit ADC, ±0.1% accuracy
Control cycle: Minimum 50μs
Trigger modes: Synchronous / Sequential / Redundant triggering
Physical Specifications:
Dimensions: 120×80×50mm
Weight: 1kg
Operating temperature: -25°C~+70°C
Protection class: IP20
Typical Applications:
Medium and high-voltage frequency converters
HVDC converter valve control
Industrial power supplies and induction heating equipment
GD9924BE V2 HIEE401091R0002 Specification Parameters:
ABB GD9924BE V2 HIEE401091R0002 High-Voltage Control Board Applications:
Power Industry:
Monitoring and control of high-voltage transmission lines
Automation systems for substations
Ensures safe and stable power transmission
Industrial Automation:
Drive control for high-power motors (e.g., rolling mill motors in steel plants, large fan motors in cement plants)
Precise regulation of motor speed and torque to improve production efficiency and product quality
Petrochemical Industry:
Accurate control of high-pressure reactors and transfer pumps
Ensures safety and stability in chemical production processes
