ABB XUD194A 3BHC018137R0001 is a module in the AC 800PEC system, which is an optical fiber repeater. AC 800PEC is a high-performance control system launched by ABB, featuring short cycle time and strong processing capability. It is widely used in industrial fields such as power electronics.
Functional purposes: It is used to extend the optical fiber communication distance and realize high-speed data transmission between devices, and can be applied in long-distance and large-capacity scenarios. For example, in the communication between ACS800 and L1 system AC800PEC, it can connect the inverter RDCO card with the drive communication module in the AC800PEC cabinet to realize the communication between the drive system and the L1 system.
Performance features: It supports multimode and single-mode optical fibers, has the characteristics of ring optical fibers, and is equipped with automatic rate detection and adaptive performance, which can automatically adapt to different optical fiber transmission rates. The XUD194A 3BHC018137R0001 module also has an optical power indication function and built-in optical fiber transceiver protection to ensure the stability and reliability of the system.
Mounting method: It adopts 35mm DIN rail mounting, which is convenient for users to install and maintain. This mounting method saves space and facilitates layout in the control cabinet.
Power supply requirements: It usually supports dual power supply redundant input, with DC (9-36) V, typically DC24V, and power consumption less than 4W. It has DC1500V voltage isolation and reverse connection protection functions to ensure stable power supply in industrial environments.
Mechanical characteristics: The XUD194A 3BHC018137R0001 generally has an outline dimension of 132mm × 105mm × 52mm. Its shell is a wavy aluminum reinforced case with IP30 protection rating, which can effectively prevent dust and foreign objects from entering, and the net weight is about 800g. The operating temperature is -10 - 70℃, some models can support a wide temperature environment of -40 - 85℃, the relative humidity is ≤90% (non-condensing), and the storage temperature is -40 - 80℃, which can adapt to relatively harsh industrial environments.
