Honeywell CPU2-3030D (including ELCM-PCB loop control board and HS-NCM-W high-speed network module) is the complete core component of Honeywell NOTIFIER ONYX series NFS2-3030 intelligent fire alarm control system. It provides centralized fire detection, alarm linkage and network management functions for medium and large-scale premises.
Integrated with dual-core processing, intelligent loop control, high-speed wired networking and long-term log storage, this suite complies with domestic and international fire protection certifications including UL 864, EN 54 and GB 26851. It is widely deployed in high-safety-level scenarios such as commercial complexes, super high-rise buildings, data centers, rail transit, airports and ports.
Core Advantages
High Performance & Large Capacity SupportDual-core ARM Cortex-A9 architecture with 800MHz main frequency; supports up to 3,180 intelligent addressable devices (10 SLC loops, 159 points per loop). Event response time is less than 50 ms, suitable for large-scale campus-level networking.
Intelligent Detection & Low False Alarm RateAdopts VIEW® early warning algorithm and drift compensation technology to distinguish smoke from interference sources. It supports automatic sensitivity testing of detectors and two-level maintenance early warning, with an annual false alarm rate lower than 0.002%.
Modular Redundant DesignCPU, power supply (AMPS-24E), loop board (ELCM-PCB) and network module (HS-NCM-W) all support redundant configuration. Seamless switching is completed within 0.3 seconds upon single-module failure to ensure continuity of critical operations.
Full-network High-speed InterconnectionThe HS-NCM-W module supports NFN high-speed network. Twisted-pair transmission reaches up to 3 km and allows networking with 100 nodes, enabling centralized management across buildings and regions.
Long-term Stable OperationEquipped with 2GB DDR3 + 4GB eMMC storage to retain event logs for 10 years. Wide operating temperature range: -40℃~+70℃ with IP30 protection rating, suitable for industrial and harsh environments.
Key Features
(1) CPU2-3030D Main Control Unit
Display & Operation: 640-character backlit LCD with QWERTY keyboard; real-time display of alarm, fault and isolation information, supporting Chinese/English bilingual.Storage & Log: Built-in auto-synchronization clock chip; 10-year event recording with retrieval by time, address or event type.Control Output: 4 NAC outputs (Class A/B); alarm, fault and supervision relays; programmable linkage logic (e.g., sprinkler activation via two-point alarm confirmation).
(2) ELCM-PCB Loop Control Board
Loop Capacity: One independent SLC loop per board, compatible with Style 4/6/7 wiring; supports FlashScan®/CLIP protocol detectors and modules.Isolation Protection: Automatically isolates short-circuited loops and restores operation after fault clearance, without affecting other devices on the network.
(3) HS-NCM-W High-speed Network Module
Communication Media: Twisted pair cable for HS-NCM-W; compliant with NFPA Class A/B, offering strong EMI resistance and eliminating ground loop risks.Networking Capability: Each module provides 2 node addresses and supports up to 100-node networking; automatic bypass upon network failure to maintain core communication.
Application Scenarios
Super High-rise Buildings: Cascade connection of 12 units of CPU2-3030D realizes full-building linkage control for 128 floors, complying with the anti-interference standard GB 50116.
Data Centers: Redundant configuration ensures zero-interruption operation of IT equipment and meets TIA-942 Tier IV fire protection requirements.
Rail Transit: Vehicle-mounted application for metro systems; adapts to tunnel temperature variation of -40℃~+70℃, successfully responding to 12 actual fire incidents.
Commercial Complexes: Ideal for large shopping malls and hotels covering multiple floors and zones. It supports partitioned alarming and evacuation guidance, and links with fire broadcasting, roller shutters and emergency elevator landing control.
Peer-level Intelligent Fire Alarm Controller Comparison
| Comparison Dimension | Honeywell CPU2-3030D | Siemens FS20 |
|---|---|---|
| Maximum Device Capacity | 3,180 points (10 loops) | 2,048 points (8 loops) |
| Response Time | ＜50ms | ＜100ms |
| False Alarm Rate | ＜0.002% | ＜0.005% |
| Networking Capability | 100 nodes (Twisted pair / Fiber) | 64 nodes (Fiber) |
| Log Storage Duration | 10-year log retention | 5-year log retention |
| Operating Temperature | -40℃~+70℃ | -30℃~+60℃ |
| Certification Standards | UL864 / EN54 / GB26851 | UL864 / EN54 |
| Price Range | High-end (Cost-effective) | High-end (Premium priced) |
FAQ
Q: The main panel reports "Loop Trouble". How to troubleshoot?A: ① Check the loop wiring for short circuit or open circuit, and verify the end-of-line (EOL) resistor is normal;② Measure loop voltage with a multimeter (normal value: 24V);③ Replace the ELCM-PCB loop control board for testing;④ Inspect loop devices for damage (e.g., water ingress in detectors).
Q: The HS-NCM-W network module shows "Network Fail" and fails to connect to the network?A: ① Verify twisted-pair wiring (A/B sequence) and ensure transmission distance ≤ 3km;② Confirm unique network node addresses with no conflict;③ Restart the module or replace the HS-NCM-W unit;④ Check main panel network configuration (baud rate / address).
Q: Detectors generate frequent false alarms. How to resolve?A: ① Enable drift compensation for automatic sensitivity calibration;② Clean dust from detectors during monthly maintenance;③ Relocate detectors away from air outlets and fume sources;④ Upgrade the main panel firmware to the latest version.
Q: Event logs are lost after main panel power failure?A: Under normal conditions, logs can be retained for 10 years without loss. If logs disappear:① Check the standby battery (12V28A) and confirm it supplies power during mains failure;② Reboot the panel and reload records via the History menu;③ Contact the manufacturer to inspect the eMMC storage module.
Q: How to configure two-point alarm linkage (e.g., sprinkler activation only when two smoke detectors alarm)?A: Enter Programming → Logic Equation → Create new logic (ZL10) → Set condition as Z1 (Smoke Detector 1) AND Z2 (Smoke Detector 2) → Associate with the sprinkler control module → Save and download configuration. The linkage will only activate when both detectors trigger an alarm simultaneously.
