ABB DSDI 120AV1 3BSE018296R1 is a 32-channel 48VDC digital input card. It belongs to the ABB S100 I/O series and is specially designed for ABB industrial control systems including Advant Master and 800xA. As a core I/O module in industrial automation control, it is used for acquisition and transmission of on-site discrete signals.
Product Advantages
High channel density for cost savingsThis module integrates 32 input channels, which reduces cabinet space occupation and module procurement quantity, cutting down overall system integration costs.
Excellent system compatibilityIt is compatible with mainstream ABB control systems including Advant Controller 450, AC460 and 800xA. It can connect to AC800M controllers via CI856 interface and works with S100 I/O rack systems.
Industrial-grade reliabilityEngineered for harsh industrial environments, it features strong anti-interference performance and stable signal transmission, suitable for long-term continuous operation.
Compliance performanceExempt from the restrictions of EU RoHS Directive (2011/65/EU), it meets environmental compliance requirements for specific industrial equipment.
DOCUMENT DOWNLOAD
Basic Specifications
Model: DSDI 120AV1, Part No.: 3BSE018296R1Number of Channels: 32 digital inputsInput Voltage: 48 VDC
Dimensions / Weight: 350 mm (Depth) × 265 mm (Width) × 10 mm (Height), Net Weight: 0.328 kg
Environmental Compliance: Non-RoHS compliant; WEEE Category 5 (Small Equipment)
Performance Features
Signal Acquisition: Accurately detects 48 VDC discrete signals, compatible with industrial sensors, limit switches, relay contacts and other input devices.
Physical Design: Slim card design, fits S100 standard racks for easy installation and maintenance.
Communication Compatibility: Supports ABB industrial bus protocols including MasterBus 300, enabling high-speed data exchange with controllers.
Application Scenarios
Power & EnergySwitch status monitoring, equipment interlock control and fault signal acquisition for power plants and substations.
Chemical & Metallurgical IndustryValve position feedback, operation status monitoring of pumps and fans, and safety interlock systems for chemical plants and metallurgical production lines.
ManufacturingSensor signal collection, workstation status feedback and input of equipment start-stop control signals on production lines for automotive, electronics and food processing industries.
Water TreatmentSignal acquisition of level switches, pressure switches and valve status in sewage treatment plants and waterworks.
Operating Instructions
Installation Preparation
Verify that the module model (3BSE018296R1) is compatible with the rack. Perform all operations with power disconnected to prevent electrostatic damage to the module.
Prepare S100 standard rack, 48VDC power supply and shielded twisted pair cables for signal transmission.
Hardware Installation
Align the module with the slot of the S100 rack, insert it smoothly and fasten the screws to ensure reliable contact between the module and rack bus.
Connect the 48VDC power supply to the module power terminals with correct polarity to avoid reverse connection.
Wire signal cables of field devices (sensors, switches) to the input channel terminals of the module. Ground the shield layer at a single end to reduce interference.
System Configuration
Add the DSDI 120AV1 module via Control Builder A software in ABB 800xA or Advant Master system.
Configure channel parameters including input type and filter time, and associate with controller program variables to link signal acquisition and logic control.
Commissioning and Operation
After power-on, use the system diagnostic function to check module communication status and confirm no hardware or communication faults.
Trigger field input devices and check status changes of corresponding channels on the system monitoring interface to verify signal acquisition accuracy.
FAQ
Q: The module fails to communicate and the indicator light is off.Troubleshooting: Check if the 48VDC power wiring is correct, whether the rack bus is loose and if the module is fully seated.Solution: Rewire and secure connections, then power cycle the module. If the issue persists, inspect for hardware faults on the module or damaged rack slots.
Q: Channel signals are unstable and fluctuate frequently.Troubleshooting: Field signal cables are unshielded, the shield is grounded at both ends, or strong electromagnetic interference exists nearby (e.g., inverters, motors).Solution: Replace with shielded twisted pair cables and apply single-end grounding. Keep cables away from high-interference equipment, and enable signal filtering if needed.
Q: Can this module be used with non-ABB systems?Answer: This is a dedicated ABB I/O module. It is only compatible with ABB 800xA, Advant Master and other ABB systems, and cannot be directly applied to third-party systems such as Siemens and Rockwell Automation.
Q: Does the module support hot swapping?Answer: Hot swapping is not supported. Cut off the system power before installing or removing the module; otherwise, the module or rack bus may be damaged.
