Model Code Breakdown
Segmented Interpretation of Full Model VALMET METSO A416013
Product Features
Application Industries
Pulp & Paper Industry
Serves as the underlying backplane for paper machine main control cabinets, digester section DCS racks and white water recovery control systems. It manages signal interaction between basis weight valves, consistency sensors and drive inverters.
Mining & Mineral Processing
Deployed in crushing and grinding production lines, flotation control systems and tailings treatment automation racks, connecting mill controllers, level gauges and hydraulic actuators.
Thermal Power & Biomass Energy
Applied to boiler DCS control systems and flue gas desulfurization & denitrification automation cabinets. It collects temperature, pressure and flow signals and interfaces with furnace regulating actuators.
Fine Chemical Process
Used in continuous reactor control systems and distillation section automation racks, transmitting 4-20mA analog signals and safety interlock digital signals.
Water Treatment Industry
Installed in control cabinets for advanced treatment of industrial wastewater and papermaking effluent, matched with online water quality monitoring instruments and dosing regulating valve drive modules.
Building Materials & Cement Industry
Equipped on DCS automation racks for kilns and raw material grinding, suitable for long-term operation in on-site cabinets with high temperature and heavy dust.
Product Comparison
Comparison of three mainstream platform backplanes from Valmet A41 series: A416013, A416008 and A416001
Slot Capacity
A416013: Standard 12-slot model;
A416008: Compact 8-slot version;
A416001: Mini 4-slot variant, designed for small standalone control cabinets.
Anti-interference Performance
A416013 adopts double-layer shielded bus circuits with 1500 V AC isolation voltage; Versions 008 and 001 only feature single-layer isolation, applicable to workshops with mild electromagnetic interference.
Fault Diagnosis Capability
A416013 is equipped with an independent log storage chip to record historical faults; 008 and 001 have no log storage function and only display real-time current faults.
Maximum Load Power Consumption
A416013: Max. 38 W at full load;
A416008: Max. 26 W at full load;
A416001: Max. 14 W at full load.
Only A416013 can be used for large-scale multi-module systems.
Applicable Scenarios
A416013: Main DCS racks for complete production lines;
A416008: Sectional sub-control cabinets;
A416001: Small local control cabinets for single machines.
Lead Time & Compatibility
A416013 is kept in regular factory stock and universally compatible for new plant construction and old production line retrofits; 001 and 008 are mostly legacy spare parts with limited factory spot supplies.
Supporting Products
Core Processor Module
A413280 CPR1 CPU main control board, the core for logical operation of the whole system, which must be installed in Slot No.1 of A416013 backplane.
Power Supply Module
A413345 rack power supply board, supplying stable 24 V DC input to the A416013 backplane.
Analog I/O Modules
A413052 analog output board and A413060 analog input board, for collecting and outputting 4-20 mA process signals.
Digital I/O Module
A413144 digital input/output board, connected to on-site valve limit signals and equipment start-stop interlock signals.
Communication Expansion Module
A413240A bus communication board, expanding communication channels for third-party instruments supporting Profibus and HART protocols.
Rack Hardware
Standard 19-inch industrial metal rack for Valmet DNA, anti-static fixing clips and backplane bus wiring harnesses.
System Software
Valmet DNA System V7.0 or higher configuration and monitoring software, used for backplane hardware identification and program downloading.
FAQ
Unplug and re-seat the module in the faulty slot;
Insert a functional spare module into the slot to identify whether the fault lies with the module or the backplane slot;
Check for abnormal voltage drop on the backplane power circuit;
Clear backplane fault logs and restart for self-inspection.
Q3: Does a single purchased A416013 come with matching bus cables and fixing clips?
A3: Standard factory supply of A416013 only includes the backplane itself. Bus wiring harnesses and metal clips are separate spare parts that need to be ordered individually as A41 series rack hardware accessories.
Q4: How to fix frequent communication disconnections of A416013 under high cabinet temperature on site?
A4:
Inspect cabinet cooling fans for failure and keep internal cabinet temperature below 60°C;
- Mount small industrial cooling fans outside the backplane;
- Ensure total module load does not exceed the rated 38W maximum power of the backplane to prevent overheating caused by overload.
Q5: Does A416013 support parallel operation of dual backplanes for redundant rack systems?
A5: Yes. Two A416013 backplanes paired with dual CPU modules can build a redundant control system. The original Valmet DNA software integrates redundant switching logic, which enables millisecond-level automatic switchover without production downtime.
Recommended Models of the Same Brand
- A416013 12-slot Platform Controller Backplane
- A416008 8-slot Compact Platform Controller Backplane
- A416001 4-slot Mini Platform Controller Backplane
- A413280 CPR1 Processor Module
- A413052 Analog Output Module
- A413060 Analog Input Module
- A413144 Digital I/O Module
- A413240A Bus Communication Expansion Board
- A413345 Rack Power Supply Module
- A413160 Pneumatic Relay Control Module
- A418081 Distributed Interface I/O Board
- A413181 PLU-1 Logic Processing Module
- A413070 HART Communication Acquisition Board
- A413200 Ethernet Repeater Board
