Yokogawa YHC5150X FieldMate Handheld Communicator

Equipped with DD Direct technology, the YHC5150X natively loads device description files without extra format conversion or ongoing subscription services. It fully complies with HART 6 and HART 7 standards, supporting all registered and unregistered HART field instruments available on the market.Featuring a high-capacity lithium battery and a 4.3-inch industrial touchscreen paired with a physical QWERTY keyboard, this communicator supports long-duration outdoor operations in ATEX hazardous areas. It serves as a mainstream commissioning tool for instrument maintenance in oil & gas and chemical projects.

• Processor: 1GHz single-core processor
• Operating System: Windows Embedded CE
• Memory: 256MB RAM, 512MB Flash; supports up to 64GB SD memory card
• Display: 4.3-inch anti-glare color touch screen, 480×272 resolution, glove-touch compatible, stylus-free operation
• Keypad: Full QWERTY keyboard + numeric function keys
• Communication Protocol: HART protocol, compatible with HART 6, HART 7
• Safety Certification: ATEX Intrinsically Safe Certification
• Dimensions: 303mm × 142mm × 48mm
• Weight: 0.91kg (including battery)
• Ingress Protection: IP51
• Operating Temperature: -20℃ ~ +55℃
• Power Supply: Built-in rechargeable lithium battery; approx. 10 hours continuous operation, 20 hours typical working duration, up to 100 hours standby
• Standard Accessories: Charging cradle, universal power adapter, HART test cable set, 250Ω loop resistor, USB data cable, portable protective case, hand strap

• DD Direct Native Reading Technology: Directly loads OEM original DD files, eliminating format conversion. No recurring paid DD subscription fees to lower long-term maintenance costs.
• Complete support for universal HART commands, common practice commands and device-specific commands. Enables one-stop operations including range modification, unit switching, alarm threshold configuration, zero & span trimming.
• Automatic polling of multiple HART instruments on a loop, fast identification of device addresses, real-time measurement data retrieval, fault code reading and firmware version check for rapid troubleshooting.
• Offline configuration: Pre-load instrument parameters inside the communicator; download configurations to field devices with one click upon arrival to shorten plant commissioning timeline.
• Data interoperability: Connect to PC via charging cradle USB for bidirectional synchronization of configuration schemes, equipment inventory and commissioning logs with PC-based FieldMate software.

• Multi-language interface with built-in help menu; customizable shortcut operations to reduce learning barriers for new engineers.

•

Product Features

• Ergonomic handheld enclosure with buffer anti-collision rubber strips around edges; withstands 1-meter drop onto concrete surfaces.
• Dual operation modes: touch screen + physical keyboard; stable screen visibility under strong outdoor sunlight.
• Intelligent power management with customizable auto-sleep timer and low-battery pop-up alert.
• Integrated HART modem ensures stable loop communication signals and reliable connection even under weak signal conditions.
• Modular hardware design; detachable and replaceable battery for extended shift operations on site.
• All fundamental communication functions are standard; no mandatory optional modules required.

Application Fields

• Oil & Gas: Commissioning and inspection of pressure, temperature and level HART instruments for long-distance pipelines, LNG terminals and onshore oilfields.
• Refining & Fine Chemicals: Routine maintenance and fault diagnosis of smart transmitters and HART valve positioners installed on reactors and distillation columns.
• Thermal Power & New Energy Power Plants: Calibration of HART smart instruments in flue gas desulfurization, denitrification and water-steam systems.
• Metallurgy & Water Treatment: Configuration of online flow and level instruments for wastewater treatment plants and metallurgical production lines.
• Pharmaceutical & Food Processing: Safe commissioning of smart instruments in explosion-proof clean areas.
• Coal Chemical & Energy Storage Projects: Periodic inspection of field instruments in hazardous classified explosion zones.

Operation Guide

1. Hardware Assembly: Install and lock the lithium battery into the YHC5150X, connect the HART test cable. Install the supplied 250Ω resistor in series if loop load is insufficient.
2. Power on: Press and hold the power key for 1 second, wait for system boot and enter the main interface, then select HART communication mode.
3. Connect the two ends of test cable to the 4–20mA signal loop of field HART instruments; the device will automatically poll all smart instruments on the loop.
4. Select the target instrument; the communicator automatically loads corresponding DD files and enters parameter page. Modify range, output, alarm and other parameters as required.
5. Write modified parameters to the instrument and save configuration records. Perform instrument self-test and loop current verification if needed.
6. Disconnect wiring after commissioning and back up configuration files in the device. Place the communicator on the charging cradle for recharging when idle.
7. For data export: Connect charging cradle to PC via USB cable, synchronize commissioning records with FieldMate software.

Working Principle

Inter-brand Model Comparison

• Battery Life: YHC5150X features more than doubled battery capacity, delivering significantly longer continuous operation time than YHC4150X.
• Display: YHC4150X adopts small monochrome screen; YHC5150X upgraded to a 4.3-inch color anti-glare touch display.
• Software Architecture: YHC4150X runs outdated embedded OS; YHC5150X uses updated Windows CE with faster computing speed and supports larger DD file storage.
• Core Technology: DD format conversion required for YHC4150X; YHC5150X adopts DD Direct native reading solution.
• Positioning: YHC4150X is legacy entry model; YHC5150X serves as upgraded replacement and fully compatible with all existing application scenarios.

Compatible Supporting Products

Our Supply Advantages

• Ready stock of YHC5150X to shorten lead time; quotation support for bulk project procurement.
• Complete accessory packages including charging cradle, test cables and resistor kits; no separate scattered purchasing required.
• Pre-shipment power-on communication testing to verify communication performance, touchscreen function and battery health of each YHC5150X unit.
