HIMA ELOPII Safety Programming Software USB Dongle
Basic Information
HIMA ELOPII Safety Programming Software USB Dongle is a hardware authorization encryption device adapted for ELOPII engineering software, part number 892042336. It must be used together with the ELOPII software package to fully unlock all engineering functions.
Without HIMA ELOPII Safety Programming Software USB Dongle, ELOPII software can only run in demo mode. Program download, online diagnosis and generation of compliant project documents will be unavailable.
This dongle targets HIMA legacy‑generation safety PLC hardware, covering HIQuad H41q, H51q and partial HIMatrix controllers. It serves configuration, commissioning, maintenance and retrofit projects for safety instrumented systems in petrochemical and energy industries.
One single HIMA ELOPII Safety Programming Software USB Dongle license supports programming for multiple sets of field hardware.
Technical Specifications
| Part Number | 892042336 |
| Hardware Interface | USB‑A |
| Supported Software | ELOPII Factory V5.6 |
| Compatible OS | Windows7, Windows10 (recommended to run under compatibility mode) |
| Programming Standard | IEC 61131‑3, LD, FBD, ST, SFC, IL |
| Safety Level | SIL3 (IEC61508) |
| Communication Protocols | SafeEthernet, Profibus‑DP, Modbus, RS‑485 |
| PC Requirement | USB2.0 port, corresponding hardlock driver installation required |
| License Mode | Single hardware dongle, unlimited number of programmable controllers |
| Disk Requirement | Minimum 500MB free local hard‑disk space |
Core Advantages
- HIMA ELOPII Safety Programming Software USB Dongle adopts hardware lock authorization. Compared with software serial numbers, it will not lose authorization due to system reinstallation or OS modification.
- License is bound to physical hardware, meeting functional‑safety audit requirements, suitable for field engineers commissioning multiple HIMA safety controllers on‑site.
- Unlocks full set of tools including offline simulation, online signal forcing, project cross‑reference, variable CSV import and export; no additional sub‑licenses needed.
- For legacy H41q, H51q systems, this dongle is essential for logic modification, fault troubleshooting and document archiving. Fully re‑uses TÜV‑certified safety function block libraries to shorten project validation cycles.
Product Features
- Compact portable USB hardware, for office configuration and field commissioning.
- Full ELOPII engineering functions activated upon detection; software reverts to demo mode after dongle removal.
- Password‑protected controller access, supports TCP/IP remote maintenance together with ELOPII software.
- License is not bound to host PC; can be swapped among multiple industrial laptops.
- Hardware encryption mechanism prevents license tampering, satisfies compliance recording for SIL3 projects.
- Works with ELOPII for offline simulation test, program download, real‑time signal monitoring and event log reading.
- Covers full project lifecycle: hardware configuration, logic development, commissioning and output of compliance report documents.
Application Fields
- Oil & Gas: Configuration and maintenance for SIS safety instrumented systems in refineries, oil‑gas pipelines and offshore platforms.
- Power & Energy: BMS burner management systems for thermal power plants, unit safety interlock retrofits.
- Petrochemical: ESD emergency shutdown systems, HIPPS over‑pressure protection commissioning and maintenance.
- Rail Transit: Program update for industrial safety interlock equipment.
- Plant Technical Retrofit: Upgrade, fault diagnosis and document completion for legacy HIMA HIQuad and HIMatrix devices.
- Third‑Party Safety Engineering: Functional‑safety service providers for multi‑project field commissioning with shared license.
Product Comparison
- HIMA ELOPII Safety Programming Software USB Dongle: Only compatible with ELOPII software, targets H41q, H51q and early‑generation HIMatrix hardware.
- SILworX License Dongle: For new‑generation HIMatrix and HIMax controllers. Not compatible with H41q/H51q. Updated software architecture, supports more modern safety controller models.
- ELOPII Parallel‑Port Dongle: Obsolete legacy hardware for ELOPII software with parallel port interface. Most modern industrial laptops no longer have parallel ports, causing heavy field‑usage limitations. Replace with HIMA ELOPII Safety Programming Software USB Dongle as preferred solution.
Related Supporting Products
- Controller Hardware: H41q‑HS, H51q‑HR, F35 01, F20, F30
- IO Modules: F3236, F3330, F3403, B5233‑1
- Communication Accessories: SafeEthernet cable, RS485 programming cable
- Software Media: ELOPII Factory V5.6 installation package
- Driver Components: Hardlock dongle driver
FAQ
Q: Can I download programs to PLC directly without HIMA ELOPII Safety Programming Software USB Dongle?
A: No. Without dongle 892042336, software runs in demo‑only mode. Users can only view projects. Program download, online monitoring and formal report export and all core operations will be disabled.
Q: Can one HIMA ELOPII Safety Programming Software USB Dongle program multiple PLC units simultaneously?
A: One single dongle can only be inserted into one PC at a time. The license itself has no controller quantity limit. Unplug and insert it into another laptop to commission other compatible HIMA hardware.
Q: Can HIMA ELOPII Safety Programming Software USB Dongle work for SILworX software?
A: No. 892042336 is exclusively for ELOPII Factory. SILworX requires separate dedicated dongle; licenses of the two systems are not interchangeable.
Q: How to handle dongle recognition failure after system reinstallation?
A: Re‑install Hardlock driver, switch to another motherboard USB port. USB2.0 port is preferred; avoid USB‑C adapters and docking stations.
Q: Does HIMA ELOPII Safety Programming Software USB Dongle support Windows11?
A: Official documentation does not cover Windows11 compatibility. Windows10 compatibility mode is recommended. Driver detection failures frequently occur under Windows11 environment.
Q: Does HIMA ELOPII Safety Programming Software USB Dongle support HIMax controllers?
A: Only very limited early‑model HIMax hardware is supported. Mainstream HIMax devices require SILworX software and corresponding dongle.
Q: Does purchasing HIMA ELOPII Safety Programming Software USB Dongle include ELOPII software installation disc?
A: Software media is not included with the dongle hardware. Installation packages need to be obtained separately. Confirm matching software version before purchase.
Related HIMA Part Numbers
F3236, F3330, F3403, F60CPU, B5233‑1, H41q‑HS, F3501, F7133, F8621, F3103, F4211
Notes
- Connect HIMA ELOPII Safety Programming Software USB Dongle directly to PC USB2.0 port. Avoid long‑term usage of USB hubs or Type‑C adapters, which may lead to intermittent recognition issues.
- This is precision electronic hardware. Prevent heavy impact, moisture and corrosive surroundings; store in dry anti‑static case.
- Confirm normal dongle recognition before SIL‑level project audits to ensure full software authorization status.
- Avoid major operating‑system version updates; new OS releases may cause driver compatibility faults.
- This hardware is intended for ELOPII V5.6. Verify license compatibility before applying for higher or lower ELOPII releases.
