IS200TBAIH1CED is an analog input/output terminal board for the GE Speedtronic Mark VIe control system.It serves as the signal interface between field sensors and the controller, responsible for acquiring analog signals such as temperature and pressure as well as outputting control signals.Widely applied in gas/steam turbine control, power generation, oil & gas, and industrial automation industries, it is one of the core components enabling high-precision and high-reliability control of the GE Mark VIe system.
Product Advantages
High Reliability and Redundancy DesignSupports simplex, duplex and Triple Modular Redundancy (TMR) configurations to eliminate single point of failure. Equipped with on-board noise suppression circuits and compliant with IEC 61000 EMC immunity standards, it adapts to harsh industrial environments such as high temperature and vibration.
High-Precision Signal Processing10 analog inputs are compatible with 2/3/4-wire or externally powered transmitters; 2 analog outputs can be configured for 0–20mA or 0–200mA. It delivers high accuracy in signal acquisition and conversion, meeting the requirements of complex control algorithms.
Strong Compatibility and Easy IntegrationSpecifically designed for the GE Mark VIe control system, it offers seamless compatibility with Mark VIe/S series modules. Built with three DC-37 connectors, it enables flexible I/O configuration and is suitable for control applications of gas turbines, steam turbines and other scenarios.
Easy Maintenance and Self-DiagnosticsModular design allows fast replacement and fault isolation. A built-in self-diagnostic chip monitors voltage fluctuations and communication anomalies in real time, with alerts via LED indicators or software alarms, effectively reducing downtime and maintenance duration.
Wide Temperature Range and Industrial ProtectionOperating temperature ranges from -40℃ to 70℃ with IP65 protection rating, enabling stable operation in extreme environments such as mines and offshore platforms.
Core Features and Application Scenarios
| Feature | Parameter / Description | Application Scenarios |
|---|---|---|
| Functional Positioning | Analog I/O terminal board, 10AI/2AO | Gas turbine control, steam turbine control, power generation system monitoring, oil and gas extraction control, industrial automated production lines |
| Input Channels | 10 channels, supporting voltage/current signals, compatible with multiple types of transmitters | Signal acquisition of temperature, pressure, flow, liquid level and other sensors |
| Output Channels | 2 channels, configurable 0-20mA/0-200mA | Analog control output for valve positioners, actuators and other equipment |
| Connector | 3 × DC-37 pin interfaces, supporting TMR/simplex redundancy | I/O module connection and redundant signal distribution for Mark VIe system |
| Operating Voltage | 24VDC (industrial standard) | Power supply for industrial control cabinets and on-site control stations |
| Mounting Method | DIN rail / slot mounting, pluggable terminals | Fast installation inside control cabinets, convenient for on-site wiring and maintenance |
Peer Mark VIe Terminal Boards
Comparison Description
I/O ChannelsGE IS200TBAIH1CED: 10 analog inputs and 2 analog outputs.GE IS200TBAIH1CDC: 10 analog inputs and 2 analog outputs.GE IS200TBAIH1CCC: 8 analog inputs and 2 analog outputs.
Output ConfigurationGE IS200TBAIH1CED: Selectable 0-20mA / 0-200mA.GE IS200TBAIH1CDC: Fixed 0-20mA.GE IS200TBAIH1CCC: Fixed 0-20mA.
Redundancy SupportGE IS200TBAIH1CED: Supports TMR, duplex and simplex modes.GE IS200TBAIH1CDC: Supports TMR and simplex modes.GE IS200TBAIH1CCC: Mainly applicable for simplex mode.
ConnectorsGE IS200TBAIH1CED: Equipped with 3 DC-37 connectors.GE IS200TBAIH1CDC: Equipped with 3 DC-37 connectors.GE IS200TBAIH1CCC: Equipped with 2 DC-37 connectors.
Diagnostic FunctionsGE IS200TBAIH1CED: Self-diagnosis with LED alarm indication.GE IS200TBAIH1CDC: Basic diagnostic functions.GE IS200TBAIH1CCC: Basic diagnostic functions.
Operating TemperatureGE IS200TBAIH1CED: -40℃ to 70℃.GE IS200TBAIH1CDC: -20℃ to 60℃.GE IS200TBAIH1CCC: -20℃ to 60℃.
Application ScenariosGE IS200TBAIH1CED: Suitable for high-end TMR redundancy and extreme operating environments.GE IS200TBAIH1CDC: Suitable for conventional TMR configuration and standard environments.GE IS200TBAIH1CCC: Suitable for simplex or duplex applications and non-critical control loops.
Price RangeGE IS200TBAIH1CED: Higher price level.GE IS200TBAIH1CDC: Medium price level.GE IS200TBAIH1CCC: Lower price level.
FAQ
Q: The LED does not light up and the board cannot be recognized after power-on.A: ① Check whether the 24VDC power supply is normal and ensure terminal wiring is secure without looseness.② Verify the DC-37 cable is properly connected with no bent pins.③ The board may be damaged by static electricity. Replace it with a spare board and take proper anti-static precautions during operation.
Q: AI channel signal fluctuates greatly and is inaccurate.A: ① Check sensor wiring and ensure correct 2/3/4-wire connection, with single-point grounding for the shield layer.② Increase the input filter parameter in software to suppress high-frequency interference.③ Calibrate the channel range to compensate for sensor deviation.
Q: No output or abnormal output from AO channel.A: ① Confirm correct wiring of the output load with no short circuit or open circuit.② Check AO channel configuration in software and ensure the current mode (0-20mA / 0-200mA) matches the load.③ If the output circuit is damaged, send the board for repair or replace it directly.
Q: In TMR redundancy mode, signals are inconsistent and alarms occur frequently.A: ① Ensure all three DC-37 cables are firmly connected with poor contact eliminated.② Reconfigure the signal voting logic in software and adjust the deviation threshold.③ Isolate the faulty single channel and replace the corresponding module.
Q: The board overheats during operation and triggers an over-temperature alarm.A: ① Make sure the cabinet cooling fan works properly with good ventilation, and the ambient temperature does not exceed 70℃.② Maintain sufficient mounting spacing for the board and keep the heat dissipation area unobstructed.③ Board aging or excessive load may cause overheating; reduce channel load or replace the board.
Q: Is it compatible with non-GE sensors or actuators?A: Yes. It is compatible as long as the signal type (voltage/current) and range are matched, and 2/3/4-wire wiring is correctly applied. It is recommended to prioritize devices with standard industrial signals to avoid compatibility issues.
