HIMA BV7046‑4 4M Data Connecting Cable
Basic Information
HIMA BV7046‑4 4M Data Connecting Cable is a 4‑meter data connecting cable for data signal transmission between internal modules of HIMA safety control system. HIMA BV7046‑4 realizes stable data interaction between safety controller units and corresponding functional modules, ensuring signal integrity and timing synchronization. It is an indispensable hardware accessory for complete set‑up of safety systems.
HIMA BV7046‑4 is compatible with corresponding series rack modules. Its physical interface and signal definition strictly comply with system bus specifications. It is applied for cabinet‑internal module interconnection wiring to avoid signal interference and maintain continuous and reliable operation of the whole safety control system.
Technical Specifications
| Cable Model | BV7046‑4 |
| Cable Length | 4 m |
| Product Type | Data Connecting Cable |
| Applicable System | HIMA safety control system bus |
| Purpose | Inter‑module data signal interconnection |
| Installation Scenario | Control cabinet internal wiring |
| Signal Type | Digital safety bus signal |
| Interface Specification | Matches HIMA corresponding module bus port |
| Operating Ambient Temperature | 0 ℃ ~ +60 ℃ |
| Protection Class | Indoor cabinet‑inside use |
| Cable Structure | Multi‑core shielded structure to reduce electromagnetic interference |
Core Advantages
- HIMA BV7046‑4 adopts shielded cable structure to reduce interference of electromagnetic environment on safety signals and prevent data loss during transmission.
- Strict dimensional tolerance for cable interfaces ensures smooth plug‑in & fit and stable connection after mating, lowering risk of contact failure.
- 4‑meter cable length meets most inter‑module wiring requirements inside control cabinets and supports flexible wiring layout.
- Signal timing complies with system bus standard to avoid module communication error reporting and data packet loss.
- Sound mechanical durability adapts to long‑term continuous operation conditions of industrial control cabinets.
Product Features
- Designed exclusively for safety‑related control system bus communication; cannot be replaced by ordinary general‑purpose cables.
- Shielding layer suppresses electromagnetic noise generated by inverters and contactors on industrial sites.
- High forming precision of interface terminals for perfect alignment with corresponding module ports.
- Flexible cable body, suitable for bending and routing inside control cabinets.
- Fully supports safety bus data interaction and guarantees data synchronization among all functional modules.
Application Fields
- Petrochemical safety interlock control system
- Thermal power plant safety protection system
- Coal chemical process safety control project
- Rail transit safety control cabinet
- Manufacturing equipment safety shutdown protection system
- Safety instrument system for oil & gas production
Same‑Brand Product Comparison
- HIMA BV7046‑4 is positioned for 4‑meter cabinet‑internal inter‑module data interconnection, focusing on high‑speed data interaction over safety bus.
- Compared with short‑size BV7046‑2 cable (2 m length for close‑range docking of adjacent rack modules), BV7046‑4 is used for connection between modules with larger span inside cabinets.
- Compared with power connection cables, BV7046‑4 only transmits data signals and does not undertake power supply circuits; it shall not be used as power cable.
- Compared with ordinary third‑party replacement cables, HIMA BV7046‑4 features fully matched bus timing and pin definition. Third‑party cables may trigger communication anomalies and affect logic judgment of the whole safety system.
Related Matching Products
- HIMA F35 Safety Controller Module
- HIMA F8650X Digital Input / Output Module
- HIMA F60DI32 Digital Input Module
- HIMA F60DO16 Digital Output Module
- HIMA F3113 Rack Backplane
Same‑Brand Model List
- F35, Safety Controller Module
- F8650X, Digital Input / Output Module
- F60DI32, Digital Input Module
- F60DO16, Digital Output Module
- F3113, Rack Backplane
- F3210, Power Supply Module
- F4204, Communication Module
- F6705, Analog Input Module
- F6706, Analog Output Module
- F3330, CPU Module
- F8621, Digital Input Module
- F8622, Digital Output Module
- F3103, Rack Backplane
- F4111, Interface Module
- F6217, Relay Output Module
Frequently Asked Questions
Q: Can HIMA BV7046‑4 be directly replaced by ordinary domestic cables?
A: Direct replacement is not recommended. Ordinary cables have inconsistent pin definitions, bus timing and shielding parameters. Replacement may lead to communication interruption and module errors, and affect action logic of safety control systems.
Q: What is the maximum extendable distance for HIMA BV7046‑4?
A: This cable has fixed specification of 4 m. It cannot be cut or extended. For wiring distance exceeding 4 m, cabinet layout shall be re‑planned; do not splice extension cables.
Q: Can HIMA BV7046‑4 transmit power signals?
A: This is a data connecting cable for bus data signal transmission only. It does not support power supply transmission and shall not be connected to power circuits.
Q: Which HIMA modules are compatible with HIMA BV7046‑4?
A: Compatible with systems composed of F35, F8650X, F60DI32, F60DO16 together with F3113 rack backplane. Please check module manuals to confirm port matching.
Q: What are the storage requirements for HIMA BV7046‑4?
A: Store in dry and ventilated environment. Keep away from humidity, dust and corrosive gas. Avoid excessive bending of cable connectors.
Q: How to troubleshoot communication faults of HIMA BV7046‑4?
A: First check whether both‑end connectors are fully inserted, inspect cable sheath for damage or sharp bending, verify no physical damage on module ports, then perform system communication diagnosis.
Q: Is HIMA BV7046‑4 applicable for outdoor cabinet wiring?
A: Designed for indoor cabinet‑internal use only. Not suitable for outdoor humid and rain‑exposed environments. Additional protective cabinets are required for outdoor scenarios.
Q: What information shall be confirmed when purchasing HIMA BV7046‑4?
A: Confirm complete model BV7046‑4, verify project system version, confirm actual wiring length required by cabinet, and check matched module models.
Notes
- Do not force‑bend interface terminals during installation of HIMA BV7046‑4 to prevent pin deformation.
- Avoid too‑small bending angle during wiring to prevent fracture of inner core wires.
- The cable is only used for bus docking between modules inside cabinets, not for long‑distance wiring of external equipment.
- Follow corresponding system manuals for installation operations. Non‑professionals shall not plug / unplug safety system cables arbitrarily.
- Inspect cable appearance before use. Do not put cables with damaged connectors or sheath into project operation.
