The GE DS200CTBAG1ADD Termination Board is specially designed for the Mark V Speedtronic control system and plays a key role in scenarios such as gas and steam turbine control. It is an analog terminal module with multiple connectors on the board, including two core bus connectors (JAI and JAJ), which can connect various devices to transmit analog signals. For example, it connects with the TCCA board to realize the input and output of 4-20mA signals. The terminal board adopts a long and narrow design, with holes at the four corners and long sides for easy installation. Voltage regulation is achieved through standardized voltage-limiting hardware components and red-coated diodes.
Specifications of GE DS200CTBAG1ADD
Functional Revision: 1A, 2D
Circuit Board Coating: Standard coating
Circuit Board Layout: Long and narrow board with holes at the four corners and long edges for hardware installation and connection; two holes have conductive materials on their edges.
Core Components: Includes resistor network arrays, relays, transistors, over 20 metal oxide varistors (MOVs), over a dozen jumper switches, and multiple capacitors and resistors.
Connector Types: Equipped with multiple connectors, including two core bus connectors (JAI and JAJ), 8PL STCA board Ionet connector, JAA TCCA board 4-20mA output signal connector, etc., for connecting different devices and transmitting various signals.
The GE DS200CTBAG1ADD Termination Board is mainly applied in industrial control systems, and plays an important role especially in the control field of gas turbines and steam turbines. As a key component of the Mark V Speedtronic control system, it is responsible for the transmission and interaction of analog signals, helping to realize the collection, conversion and transmission of signals during turbine operation, ensuring the stable and efficient operation of the turbine control system, and is widely used in industries such as electric power and energy that rely on large-scale turbine equipment.
